Programming instructions

Programming the Status Register System
Status Byte Group
Chapter 3 111
Status Byte Register
Table 3-3 Status Byte Register Bits
Bit Description
0,1 Unused. These bits are always set to 0.
2 Error/Event Queue Summary Bit. A 1 in this bit position indicates that the SCPI error
queue is not empty. The SCPI error queue contains at least one error message.
3 Data Questionable Status Summary Bit. A 1 in this bit position indicates that the Data
Questionable summary bit has been set. The Data Questionable Event Register can then be
read to determine the specific condition that caused this bit to be set.
4 Message Available. A 1 in this bit position indicates that the signal generator has data ready
in the output queue. There are no lower status groups that provide input to this bit.
5 Standard Event Status Summery Bit. A 1 in this bit position indicates that the Standard
Event summary bit has been set. The Standard Event Status Register can then be read to
determine the specific event that caused this bit to be set.
6 Request Service (RQS) Summary Bit. A 1 in this bit position indicates that the signal
generator has at least one reason to require service. This bit is also called the Master Summary
Status bit (MSS). The individual bits in the Status Byte are individually ANDed with their
corresponding service request enable register, then each individual bit value is ORed and input
to this bit.
7 Standard Operation Status Summary Bit. A 1 in this bit position indicates that the
Standard Operation summary bit has been set. The Standard Operation Event Register can
then be read to determine the specific condition that caused this bit to be set.
Query: *STB?
Response: The decimal sum of the bits set to 1 including the MSS bit.
Example: The decimal value 136 is returned when the MSS bit is set low (0).
Decimal sum = 128 (bit 7) + 8 (bit 3)
The decimal value 200 is returned when the MSS bit is set high (1).
Decimal sum = 128 (bit 7) + 8 (bit 3) + 64 (MSS bit)
