Error Messages Agilent Technologies ESG Family Signal Generators Serial Number Prefixes: (Affix Label Here) Part No.
Contents Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Error Message Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Error Message Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 0: No Error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ESG Family Signal Generators Introduction If an error condition occurs in the signal generator, it is reported to both the front panel display error queue and the SCPI (remote interface) error queue. These two queues are viewed and managed separately. NOTE When there is an unviewed message in the front panel error queue, the ERR annunciator appears on the signal generator’s display.
Error Message Format ESG Family Signal Generators Error Message Format The system-defined error numbers are chosen on an enumerated (“1 of N”) basis. The SCPI-defined error numbers and the portions of the error query response are displayed on the instrument. In this chapter, an explanation is included with each error to further clarify its meaning. The first error described in each class (for example, -400, -300, -200, -100) is a “generic” error.
ESG Family Signal Generators Error Message Types Error Message Types Events do not generate more than one type of error. For example, an event that generates a query error will not generate a device-specific, execution, or command error. Query Errors (–499 to –400) indicate that the instrument’s output queue control has detected a problem with the message exchange protocol described in IEEE 4888.2, Chapter 6. Errors in this class set the query error bit (bit 2) in the event status register (IEEE 488.
0: No Error ESG Family Signal Generators 0: No Error 0 No error, No Error Message(s) in Queue The queue is empty. Every error in the queue has been read, or the queue was purposely cleared using either the Clear Error Queue(s) softkey or *CLS.
ESG Family Signal Generators -499 to -400: Query Errors -499 to -400: Query Errors The instrument’s output queue control has detected a problem with the message exchange protocol described in IEEE 4888.2, Chapter 6. Errors in this class set the query error bit (bit 2) in the event status register (IEEE 488.2, section 11.5.1). These errors correspond to message exchange protocol errors described in IEEE 488.2, 6.5.
-399 to -300: Device-Specific Errors ESG Family Signal Generators -399 to -300: Device-Specific Errors Some device operations did not properly complete, possibly due to an abnormal hardware or firmware condition. These codes are also used for self-test response errors. Errors in this class set the device-specific error bit (bit 3) in the event status register (IEEE 488.2, section 11.5.1).
ESG Family Signal Generators -399 to -300: Device-Specific Errors Self-test failed; Burst Generator Memory Test @ 0x____ The burst generator memory failed. Modulation data produced by the burst generator may not be correct. However, if an Unable to check Burst Generator Memory error was also seen, this result is not conclusive. The address of the first location that failed is reported. Report this error to the nearest Agilent Technologies sales or service office.
-399 to -300: Device-Specific Errors ESG Family Signal Generators Out of memory There was insufficient working memory during data generation pattern calculations. Reduce the size of any sweep lists and try again. Out of memory If this occurs during a memory catalog display, it means the system did not have enough free RAM to prepare the catalog. Out of memory; ARB communication failed. There was insufficient memory to complete the dual arbitrary waveform generator (Option UND) communications.
ESG Family Signal Generators -399 to -300: Device-Specific Errors Out of memory; Complementary Cumulative Distribution. Display cannot function. There is insufficient working memory available. Report this error to the nearest Agilent Technologies sales or service office. Out of memory; Could not copy current istate. An instrument state operation, such as save/recall, could not allocate enough space to copy an instrument state. The operation is aborted. Out of memory; Display system out of memory.
-399 to -300: Device-Specific Errors ESG Family Signal Generators Out of memory; Histogram display cannot function. There is insufficient working memory available. Report this error to the nearest Agilent Technologies sales or service office. Out of memory; Impulse response display cannot function. There is insufficient working memory available. Report this error to the nearest Agilent Technologies sales or service office. Out of memory; There is insufficient memory to copy the current pattern.
ESG Family Signal Generators -399 to -300: Device-Specific Errors Out of memory; Memory allocation error. There is insufficient working memory available. Report this error to the nearest Agilent Technologies sales or service office. Out of memory; Memory catalog failed. There is not enough memory to complete a catalog listing. Reduce the size of any sweep lists and try again. Out of memory; Memory request failed, out of indices. Memory request greater than total memory size.
-399 to -300: Device-Specific Errors ESG Family Signal Generators Out of memory; There is not enough memory to create the modulation. Baseband cannot function. There is not enough memory to create the modulation map. Reduce the size of any list/sweep, and preset the source to clear up any inconsistencies. If the problem persists report this error to the nearest Agilent Technologies sales or service office. Out of memory; Object Memory Area Indicates that memory was exhausted during instrument power-on.
ESG Family Signal Generators -399 to -300: Device-Specific Errors Out of memory; Unable to check Data Generator memory. There was not enough memory in the system to properly complete the data generator memory test. This does not imply a data generator memory failure. Check all other error messages to identify possible causes, discontinue list/sweep mode to free some memory, and repeat the test. Out of memory; Unable to display format window.
-399 to -300: Device-Specific Errors ESG Family Signal Generators Configuration memory lost; Persistent state checksum is bad. Using factory defaults. The persistent state is corrupt and had to be reinitialized with the factory preset values. Configuration memory lost; Persistent state preset. Using factory defaults. The persistent state has been forced to return to factory preset values. Configuration memory lost; Persistent state version is bad. Using factory defaults.
ESG Family Signal Generators -399 to -300: Device-Specific Errors System error; Cannot change manual point until list mode error condition cleared. An error is keeping the sweep/list from being able to set the frequency and/or power. Until the problem is addressed, the manual point cannot be changed. System error; File Not Found. The specified file cannot be found. Verify that the file exists in the instrument file system.
-299 to -200: Execution Errors ESG Family Signal Generators -299 to -200: Execution Errors An error has been detected by the instrument’s execution control block. Errors in this class set the execution error bit (bit 4) in the event status register (IEEE 488.2, section 11.5.1).
ESG Family Signal Generators -299 to -200: Execution Errors Program runtime error; Floating-Point Exception A floating-point math error (such as a divide by zero) has been detected. The system will attempt to recover automatically. Report this error to the nearest Agilent Technologies sales or service office. -285 Program syntax error A syntax error appears within a downloaded program. The syntax used when parsing a downloaded program is device-specific.
-299 to -200: Execution Errors -276 ESG Family Signal Generators Macro recursion error A syntactically legal macro program data sequence could not be executed because the device found it to be recursive (see IEEE 488.2, 10.7.6.4). -275 Macro definition too long A syntactically legal macro program data sequence could not be executed because the string or block contents were too long for the device to handle (see IEEE 488.2, 10.7.6.1).
ESG Family Signal Generators -260 -299 to -200: Execution Errors Expression error An expression data element-related error occurred. This error message is used when the device cannot detect the more specific errors described for errors -261 through -269. -258 Media protected The device or user has attempted to write to a read-only memory subsystem (msus). The definition of a protected media is device-specific.
-299 to -200: Execution Errors ESG Family Signal Generators File name error; Illegal filename character An illegal character was used within a filename. \, :, @ and all non-printable ASCII characters are illegal in filenames. File name error; Only one “:” is allowed. Indicates that only one colon is allowed in any filename specification. The text before the colon is a user memory subsystem. File name error; Only one “@” is allowed. Indicates that only one @ is allowed in any filename specification.
ESG Family Signal Generators -299 to -200: Execution Errors File name not found; The internal list file was not found. There is no list data to return The DWEL_FILE, FREQ_FILE, or POW_FILE has been lost, so a new one will have to be created. These files are the persistent information for list/sweep mode. They contain the dwell list, the frequency list, or the power list. Invoking the list editor will recreate the missing file to a length of one element.
-299 to -200: Execution Errors -254 ESG Family Signal Generators Media full A legal program command or query could not be executed because the media was full. For example, there is was no space left on the disk. The definition of what constitutes full media is device-specific. Media full; Save a state register ignored. The state memory subsystem STATE: did not have enough room to save a register. You must free some memory by deleting a file or register using Catalog. Afterwards, try again.
ESG Family Signal Generators -252 -299 to -200: Execution Errors Missing media A legal program command or query could not be executed because of missing media, for instance no disk in the disk drive. The definition of what constitutes missing media is device-specific. Missing media If this occurs during a memory catalog display, it means the default memory system could not be located. The instrument is likely not functioning properly.
-299 to -200: Execution Errors ESG Family Signal Generators Hardware missing; no such SIO address The expected board is not installed. Report this error to the nearest Agilent Technologies sales or service office. -240 Hardware error A legal program command or query could not be executed because of a hardware problem in the device. The definition of what constitutes a hardware problem is completely device-specific.
ESG Family Signal Generators -299 to -200: Execution Errors Data corrupt or stale; . The sequence file that you are attempting to run is the wrong size. Data corrupt or stale; differs offset 0x: NVRAM 0x, EEPROM 0x. This message can occur only if full power-on EEPROM comparison mode is set by the factory.
-299 to -200: Execution Errors ESG Family Signal Generators Data corrupt or stale; License file is obsolete, missing entries defaulted. This error can only occur during the instrument’s first power up after having downloaded new firmware. It indicates that the software license file is missing entries for options supported by the current revision of firmware. The missing entries have been added to the file, and their license key values have been defaulted to zero.
ESG Family Signal Generators -223 -299 to -200: Execution Errors Too much data A legal program data element of block, expression or string type was received that contained more data than the device could handle due to memory or related device-specific requirements. Too much data; The current setting results in too many data points. A new symbol map cannot be generated. CDMA2000 has been turned off. Due to a hardware limitation, only a certain number of unique data points can be created for the IQ map.
-299 to -200: Execution Errors ESG Family Signal Generators Due to a hardware limitations, only a certain number of unique data points can be created for the IQ map. This channel power level has resulted in an IQ map that exceeds the hardware limit when turned on, and cannot be accommodated. The channel has been turned off to retain a valid signal. To turn this channel on, try a different power setting or turn some other channel off. Too much data; The number of CDMA channels exceeds the maximum allowed.
ESG Family Signal Generators -299 to -200: Execution Errors Too much data; Only 16 distinct values are allowed for I and Q values. Option UN8 cannot use an I/Q map that has more than 16 unique values defined for I and Q (distinct values are listed in the I/Q table editor). You can use global search and replace to replace all occurrences of a given value (in both I and Q) with a different value. Too Much Data; Only 16 distinct values are allowed for I and Q values.
-299 to -200: Execution Errors ESG Family Signal Generators Data out of range; Manual point exceeds list sizes. Limiting to maximum point. The sweep/list manual point has been reassigned to a smaller number value due to the longest list decreasing in size or being turned off. Its new value is the length of the longest enabled list (frequency or power). Data out of range; Manual point exceeds frequency list size. Limiting to maximum point.
ESG Family Signal Generators -299 to -200: Execution Errors Data out of range; value clipped to upper limit. An input value is above the maximum value allowed. Examples: frequency setting, reference, or offset; output power; power reference and offset; modulation depth, deviation, or modulation source frequency; number of points and start/stop values for list mode; start/stop values for internal I/Q calibration; sequence or register values (save/recall); dwell time.
-299 to -200: Execution Errors ESG Family Signal Generators Settings conflict; Cannot have a secondary frame with alternate amplitude. The secondary frame is unchanged. The secondary frame feature has many potential conflicts. Some of the conflicts leave the secondary pattern and its state as they were prior to the command that led to the error message, and some turn off the secondary state, since the primary state is not compatible and it has priority.
ESG Family Signal Generators -299 to -200: Execution Errors Settings conflict; Cannot have more than 4 EDGE multiframe timeslots on simultaneously. The selected timeslot has been turned off. An unsupported timeslot type was encountered. EDGE does not support the simultaneous activation of more than four multiframe timeslots. Settings conflict; Cannot have uplink protocols while the control frame is on. Frames 1-17 timeslots changed to downlink.
-299 to -200: Execution Errors ESG Family Signal Generators Settings conflict; The current data rate is not valid for this radio configuration. Data rate changed to the default rate. The new radio configuration does not support the current data rate. The data rate changes to the default rate for the new radio configuration, which is 1× for F-FCH and 2× for F-SCH. Settings conflict; Current file length does not have an integer number of symbols.
ESG Family Signal Generators -299 to -200: Execution Errors Settings conflict; Continuous & Discontinuous setting conflict. All selected Continuous timeslots are now switched to Discontinuous. Indicates that while in TETRA mode, an attempt has been made to simultaneously assign continuous and discontinuous protocols to the timeslots. Continuous and discontinuous protocols cannot coexist in TETRA mode.
-299 to -200: Execution Errors ESG Family Signal Generators Settings conflict; EDGE BERT requires Normal as Timeslot Type. An unsupported timeslot type was encountered. The measurement timeslot must be designated Normal. Settings conflict; Enabled mod source conflicts with previously enabled mod source. Previous mod disabled. The signal generator has three sources: INT, EXT1, and EXT2 that are shared by the FM1/PM1, AM1/AM2, FM2/PM2, pulse (INT and EXT2), and burst envelope (EXT1 only).
ESG Family Signal Generators -299 to -200: Execution Errors Settings conflict; FM2/PM2 value set greater than FM1/PM1 value. FM1/PM1 changed to match FM2/PM2 value. FM2/PM2 deviation must be FM1/PM1 deviation. This error is reported when both FM1/PM1 and FM2/PM2 are enabled and an adjustment to either FM2/PM2 deviation causes the FM2 or PM2 deviation to be greater than the FM1 or PM1 deviation.
-299 to -200: Execution Errors ESG Family Signal Generators Settings conflict; Frequency list and power list are of unequal size. Turn one list off, set one to size one, or make their sizes equal. The frequency list has more than one element and the power list has more than one element, and they are not of equal size. If any of the frequency, power, or dwell lists have more than one element, they must all have the same number of elements.
ESG Family Signal Generators -299 to -200: Execution Errors Settings conflict; Incompatible step sweep frequency setting. Start, stop, center or span setting changed to be compatible with last command. Incompatible step sweep frequency setting. Start, stop, center or span setting changed to be compatible with last command. Settings conflict; Incompatible step sweep power setting. Start, stop, center or span setting changed to be compatible with last command. Incompatible step sweep power setting.
-299 to -200: Execution Errors ESG Family Signal Generators Settings conflict; I/Q & AM WB cannot be on at the same time. The modulation types I/Q and AM WB cannot be used at the same time. This error is reported when the user attempts to activate one type of modulation while the other is activated. The modulation type that was most recently requested will be turned on and the modulation that was on at the time will be turned off.
ESG Family Signal Generators -299 to -200: Execution Errors Settings conflict; Pulse modulation cannot be on with internal burst. There is a hardware conflict between pulse modulation and internal burst. The most recently requested modulation is turned on, the previous modulation is turned off. Settings conflict; Pulse period set less than pulse width. Pulse width changed to match period value. A pulse period has been entered that is smaller than the pulse width.
-299 to -200: Execution Errors ESG Family Signal Generators Settings conflict; RDCCH is only defined for Radio Configuration 3 and 4. You must set one of these Radio Configurations before configuring or using this code channel. An attempt was made to setup the R-DCCH while in a radio configuration that does not support this channel. This channel is only available in RC3 and RC4. If the R-DCCH is the desired channel, you must change to the proper radio configuration before continuing.
ESG Family Signal Generators -299 to -200: Execution Errors Settings conflict; RSCH is only defined for Radio Configuration 1 and 2. You must set one of these Radio Configurations before configuring or using this code channel. The command attempted to enter a value or setting for the R-SCH in RC1 or 2. If this is the correct R-SCH, change to the desired radio configuration and resend the command. If not, select the command for the desired R-SCH.
-299 to -200: Execution Errors ESG Family Signal Generators Settings conflict; The selected external trigger setting conflicts with the previous setting. The external trigger has been set to positive edge for one trigger source and negative edge for another trigger source. Settings conflict; Uplink & Downlink setting conflict. All selected Uplink timeslots are now set to Downlink. An Uplink timeslot type has been selected while another timeslot(s) has Downlink selected.
ESG Family Signal Generators -299 to -200: Execution Errors Settings conflict; Walsh length invalid! Changed to default Walsh number. The current Walsh length is invalid for the current data rate. For data rate 2X and above, doubling the rate halves the Walsh space. The channel Walsh number has been changed to the highest valid Walsh code. Settings conflict; You may not set Forward Link values while in Reverse Link. Reset Link Direction to proceed.
-299 to -200: Execution Errors -220 ESG Family Signal Generators Parameter error A program data element related error has occurred. This particular error message is used if the device cannot detect a more specific error described for errors -221 through -229. Parameter error; The specified file is not a modulation file type. -215 Arm deadlock The arm source for the initiation of a measurement is set to GET and a subsequent measurement query is received.
ESG Family Signal Generators -299 to -200: Execution Errors Init ignored; Unable to sweep due to sweep being in an error state. The sweep error should be fixed. The number of list, power, and/or dwell points are in conflict, or a serious system error has occurred in list/sweep. A previous error report should have described the error that is stalling list/sweep. -212 Arm ignored An arming signal was received and recognized by the device but was ignored.
-299 to -200: Execution Errors ESG Family Signal Generators Execution Error; Cannot update FlexDG with Even Second Delay. There is an error with the cdma2000 hardware. Try turning CDMA2000 mode off and on again to reset the card. If the problem persists, report this error to the nearest Agilent Technologies sales or service office. Execution Error; Cannot write user file to FlexDG. There is a hardware error associated with the current CDMA format (cdma2000 or W-CDMA).
ESG Family Signal Generators -199 to -100: Command Errors -199 to -100: Command Errors The instrument’s parser detected an IEEE 488.2 syntax error. Errors in this class set the command error bit (bit 5) in the event status register (IEEE 488.2, section 11.5.1). In this case: • Either an IEEE 488.2 syntax error has been detected by the parser (a control-to-device message was received that is in violation of the IEEE 488.2 standard.
-199 to -100: Command Errors -170 ESG Family Signal Generators Expression data error This error, as well as errors -171 through -179, are generated when parsing an expression data element. This particular error message is used if the device cannot detect a more specific error. -168 Block data not allowed A legal block data element was encountered, but not allowed by the device at this point in the parsing. -161 Invalid block data A block data element was expected, but was invalid (see IEEE 488.2, 7.
ESG Family Signal Generators -150 -199 to -100: Command Errors String data error This error, as well as errors -151 through -159, are generated when parsing a string data element. This particular error message is used if the device cannot detect a more specific error. -148 Character data not allowed A legal character data element was encountered where prohibited by the device. -144 Character data too long The character data element contains more than twelve characters (see IEEE 488.2, 7.7.1.4).
-199 to -100: Command Errors -128 ESG Family Signal Generators Numeric data not allowed A legal numeric data element was received, but the device does not accept one in this position for the header. -124 Too many digits The mantissa of a decimal-numeric data element contained more than 255 digits excluding leading zeros (see IEEE 488.2, 7.7.2.4.1). -123 Exponent too large The magnitude of an exponent was greater than 32000 (see IEEE 488.2, 7.7.2.4.1).
ESG Family Signal Generators -110 -199 to -100: Command Errors Command header error An error was detected in the header. This message is used when the device cannot detect the more specific errors described for errors -111 through -119. -109 Missing parameter Fewer parameters were received than required for the header. For example, the *ESE common command requires one parameter, so receiving *ESE is not allowed. -108 Parameter not allowed More parameters were received than expected for the header.
-199 to -100: Command Errors ESG Family Signal Generators Syntax error An unrecognized command or data type was encountered. For example, a string was received when the device does not accept strings. -101 Invalid character A syntactic command contains a character that is invalid for that type. For example, a header containing an ampersand, SETUP&. This error might be used in place of error numbers -114, -121, -141 and some others. -100 Command error; Unable to set new frequency with UP/DN command.
ESG Family Signal Generators 201 to 702: Device-Specific Errors 201 to 702: Device-Specific Errors Some device operations did not properly complete, possibly due to an abnormal hardware or firmware condition. These codes are also used for self-test response errors. Errors in this class set the device-specific error bit (bit 3) in the event status register (IEEE 488.2, section 11.5.1). The string for a positive error is not defined by SCPI.
201 to 702: Device-Specific Errors ESG Family Signal Generators A STATe: file could not be saved due to insufficient space, file corruption, or another related problem. I/O error; Trailing zero found in . Fixing... A compressed state file has a zero at its end. This is a sign of file corruption. The device fixes the problem by concealing the zero such that it no longer triggers an error message. The file may be corrupt or unusable. I/O error; The user file is too large.
ESG Family Signal Generators 201 to 702: Device-Specific Errors The firmware has changed the attenuator setting because, while in attenuator hold mode, a change in frequency setting has forced the ALC beyond its range. Attenuator hold setting over range; Power set to lower limit.
201 to 702: Device-Specific Errors 513 ESG Family Signal Generators 1 GHz Oscillator unlocked The 1 GHz reference oscillator is unlocked. If an external reference is connected, check the frequency. If this error reoccurs when no external reference is connected, the instrument may require service. 514 Reference Oven cold The reference oven is not at the required operating temperature. This is normal if the instrument has been powered down for a while.
ESG Family Signal Generators 201 to 702: Device-Specific Errors Calibration failure; DCFM DC overrange The instrument was unable to perform a DCFM or DCΦM calibration due to the input signal being outside of the offset range that can be calibrated for. Calibration failure; I/Q cal. While executing the internal I/Q calibration, the attempt to allocate memory for the calibration failed. Calibration failure; I/Q cal failed to allocate memory.
201 to 702: Device-Specific Errors ESG Family Signal Generators Uncalibrated signal; Quadrature Skew Not Calibrated A calibration is required to use the quadrature skew feature. The quadrature skew may be functional, but is not guaranteed to meet specifications until the I/Q impairment adjustment is performed. Refer to the calibration guide. 520 Sampler unlocked One of the signal generator’s samplers is unlocked or one of the sampler circuits are malfunctioning. The instrument may require service.
ESG Family Signal Generators 605 201 to 702: Device-Specific Errors DSP FW download failed. The instrument’s firmware was unable to successfully initialize the internal digital signal processor (DSP) on the A14 CPU/Motherboard. Report this error to the nearest Agilent Technologies sales or service office. DSP FW download failed; Demodulator board The instrument’s firmware was unable to successfully initialize the internal digital signal processor (DSP) on the Demodulator board (Option 300).
201 to 702: Device-Specific Errors ESG Family Signal Generators DSP times out; Demodulator communication failed The digital signal processor (DSP) on the Demodulator board (Option 300) failed to respond within the appropriate amount of time. If cycling power does not correct the problem, report this error to the nearest Agilent Technologies sales or service office. DSP times out; FlexDG communication failed The instrument is unable to communicate with the FLEXDG data generator board.
ESG Family Signal Generators 201 to 702: Device-Specific Errors DSP returns error; ARB data line error (code) The dual arbitrary waveform generator (Option UND) digital signal processor (DSP) detected an internal error when processing a command. The DSP specific error code is displayed in the parenthesis. Report this error to the nearest Agilent Technologies sales or service office.
201 to 702: Device-Specific Errors 616 ESG Family Signal Generators Configuration Error; Attenuator configuration does not match actual installed attenuator type. A mismatch was found between the configured and detected attenuator types. The instrument may not be fully functional. Report this error to the nearest Agilent Technologies sales or service office. Configuration Error; Option reconfiguration failed. As a part of option reconfiguration, the instrument reboots.
ESG Family Signal Generators 201 to 702: Device-Specific Errors Configuration error; Installed board not supported. An option board or board combination that is not supported by the installed firmware has been specified or detected. Be sure that you have the proper instrument and firmware to support the option board, and that you have specified a supported combination of options. Configuration error; Invalid Data Generator memory configuration.
201 to 702: Device-Specific Errors ESG Family Signal Generators Configuration error; Old bootrom detected. File system and instrument state re-initialized due to firmware upgrade. Replace bootrom to avoid this in the future. The firmware has detected that the instrument contains an old bootrom version. As a result the user file system, arb file system (if present), and instrument states have been re-initialized. Instrument calibration files have not been affected.
ESG Family Signal Generators 201 to 702: Device-Specific Errors DSP code is invalid; Flex DG DSP code is invalid. The version number of the DSP firmware in the FlexDG data generator is not the version expected by the instrument firmware. The instrument must be upgraded to a matching set of DSP and instrument firmware. DSP code is invalid; Incorrect demodulator boot code revision. The demodulator board has an invalid revision of DSP boot code. DSP code is invalid; Incorrect FPGA revision on Option UN7.
201 to 702: Device-Specific Errors 621 ESG Family Signal Generators FPGA download failed; Demodulator board. The download of the field programmable gate array code to the Demodulator board failed. FPGA download failed; Opt UN7. The download of the field programmable gate array code to the RAM on the A6 bit error rate tester board failed. Report this error to the nearest Agilent Technologies sales or service office. 622 Sequence references self; .
ESG Family Signal Generators 201 to 702: Device-Specific Errors State Save Recall Error; Recall data different from FW revision. No instrument state change. An attempt was made to recall a state that was saved with an incompatible version of the instrument firmware. This typically occurs when a state file is copied from an instrument with a newer version of firmware to an instrument with an older version of firmware. Newer versions of instrument firmware can read older state files.
201 to 702: Device-Specific Errors ESG Family Signal Generators Load/Store Error; Cannot create a shape with less than 2 points. Burst shape files must have two or more points for both the rise and the fall shape specification. Load/Store Error; Invalid modulation file. The user modulation file is invalid. The file is either corrupt or is not a modulation file. Load/Store Error; Operation not allowed in Fail-Safe Preset Mode.
