SCPI Command Reference 6
N9340A User’s Guide 155
TRIGer Subsystem
Trigger subsystem is only valid when the analyzer
is in zero span.
External Trigger Slope
:TRIGer[:SEQuence]:EXTernal:SLOPe
POSitive|NEGative
:TRIGer[:SEQuence]:EXTernal:SLOPe?
The external trigger signal must be a TTL signal at
0 V to 5 V. This function controls the trigger
polarity (for positive or negative- going signals).
Trigg er Source
:TRIGer[:SEQuence]:SOURce
IMMediate|VIDeo|EXTernal
:TRIGer[:SEQuence]:SOURce?
This command sets the source (or type) of
triggering used to start a measurement.
• Immediate is free- run triggering.
• Video triggers on the video signal level.
• External allows you to connect an external
trigger source.
Video Trigger Level Amplitude
:TRIGer[:SEQuence]:VIDeo:LEVel <ampl>
:TRIGer[:SEQuence]:VIDeo:LEVe?
This command specifies the video trigger level.
*RST state: Positive
*RST state: Immediate (free-run triggering)
Key access: [Span] > {Trigger}
*RST Value: 0.00 dBm
Key Access: [Span] > {Trigger}
