SCPI Command Reference 6
N9340A User’s Guide 129
DISPlay Subsystem
The DISPlay subsystem controls the selection and
presentation of textual, graphical, and trace
information. Within a display, information may be
separated into individual windows.
Turn the Entire Display On/Off
:DISPlay:ENABle OFF|ON|0|1
This command turns the display on or off. Having
the display turned off may increase the repetitive
measurement rate.
Trace Y-Axis Scaling
:DISPlay:WINDow:TRACe:Y[:SCALe]:PDIVision
1|2|5|10
:DISPlay:WINDow:TRACe:Y[:SCALe]:PDIVision?
This command sets the per-division display scaling
for the y- axis when the scale type of the Y axis is
set to Log.
*RST state: On
*RST value: 10 dB
Range: 1, 2, 5 or 10
Key access: [AMPTD] > {Scale/DIV}
