6 SCPI Command Reference
122 N9340A User’s Guide
Define Limit Pattern Values
:CALCulate:LLINe[1]:DATA
<x-axis>,<ampl>{,<x-axis>,<ampl>}
:CALCulate:LLINe[1]:DATA?
This command defines limit pattern values, and
deletes all existing data. The N9340A allows you to
set as many as four points to compose the limit
pattern by connecting them together.
<x- axis> can be a frequency or time axis.
• <x-axis> – are variables in frequency or time
domain as specified by
:CALCulate:LLINe[1]:PATTern:DOMain
FREQ|TIME
.
• <ampl> – amplitude values are in the current
Y- axis units.
*RST state: Off
Key access: [Limit] > {Set Pattern}
Domain Valid unit
Frequency Hz, kHz, MHz, GHz
Time ms, ms, s, ks
