Series N5700 User’s Guide 93
Appendix B
Verification and Calibration
Verification .........................................................................................................94
Calibration ........................................................................................................113
The verification procedures described in this appendix verify that the
power supply is operating normally and is within published
specifications.
This appendix also includes calibration procedures for the Agilent
N5700 power supplies. Instructions are given for performing the
procedures from a controller over the GPIB.
NOTE
Perform the verification tests before calibrating your power supply. If the power
supply passes the verification tests, the unit is operating within its calibration
limits and does not need to be re-calibrated.
The recommended calibration interval for Agilent N5700 power
supplies is one year.
