5 Language Reference
64 Series N5700 User’s Guide
SCPI Command Summary
NOTE
Some [optional] commands have been included for clarity. All settings
commands have a corresponding query.
Subsystem Commands
SCPI Command Description
ABORt Aborts the triggered action
CALibrate
:CURRent[:LEVel] Calibrates the output current programming
:DATA <NRf> Enters the calibration value
:DATE <”SPD”> Sets the calibration date
:LEVel P1 | P2 Advances to the next calibration step
:PASSword <NRf> Sets the numeric calibration password
:STATE <Bool> [,<NRf>] Enables/disables calibration mode
:VOLTage[:LEVel] Calibrates the output voltage programming
INITiate
[:IMMediate][:TRANsient] Initiates the trigger system
:CONTinuous[:TRANsient] Enables/disables continuous triggers
MEASure
[:SCALar]
:CURRent[:DC]? Returns the measured output current
:VOLTage[:DC]? Returns the measured output voltage
OUTPut
[:STATe] <Bool> Enables/disables the specified output
:PON
:STATe RST | AUTO Programs the Power-On State
:PROTection
:CLEar Resets latched protection
[SOURce:]
CURRent
[:LEVel]
[:IMMediate][:AMPLitude] <NRf+> Sets the output current
:TRIGgered[:AMPLitude] <NRf+> Sets the triggered output current
:PROTection
:STATe <Bool> Enables/disables over-current protection
VOLTage
[:LEVel]
[:IMMediate][:AMPLitude] <NRf+> Sets the output voltage
:TRIGgered[:AMPLitude] <NRf+> Sets the triggered output voltage
:LIMit
:LOW <NRf+> Sets the low-voltage limit
:PROTection
[:LEVel] <NRf+> Sets the over-voltage protection level
