Series N5700 User’s Guide 123
Appendix D
Compatibility
Differences – In General................................................................................124
Compatibility Command Summary...............................................................125
The Agilent N5700 power supplies are programmatically compatible
with the Agilent 603xA power supplies. This means that you can
remotely program the Agilent N5700 power supplies using the same
commands that are used to program the 603xA power supplies.
CAUTION
Do not mix Compatibility with SCPI commands in the same program. This will
result in unpredictable instrument behavior.
