Appendix B Verification and Calibration
112 Series N5700 User’s Guide
Test Record Form – Agilent N5752A and N5772A
Agilent N5752A and N5772A Report No _______________ Date __________________
Description Model Minimum Specs. Results Maximum Specs.
Voltage Programming & Readback
Minimum Voltage Vout
Front Panel Display Readback
High Voltage Vout
Front Panel Display Readback
Both
Both
Both
Both
− 300 mV
Vout − 600 mV
599.4 V
Vout − 1.2 V
__________
__________
__________
__________
+ 300 mV
Vout + 600 mV
600.6 V
Vout + 1.2 V
CV Load Effect Both − 62 mV __________ + 62 mV
CV Source Effect Both − 62 mV __________ + 62 mV
CV Ripple and Noise
peak-to-peak
rms
Both
Both
N/A
N/A
__________
__________
300 mV
60 mV
Transient Response
Voltage @ 2ms
Both
− 1 V
__________
+ 1 V
Current Programming & Readback
Minimum Current Iout
Front Panel Display Readback
High Current Iout
Front Panel Display Readback
N5752A
N5772A
N5752A
N5772A
N5752A
N5772A
N5752A
N5772A
− 1.3 mA
− 2.6 mA
Iout − 3.9 mA
Iout − 7.8 mA
1.2974 A
2.5948 A
Iout − 5.2 mA
Iout − 10.4 mA
__________
__________
__________
__________
__________
__________
__________
__________
+ 1.3 mA
+ 2.6 mA
Iout + 3.9 mA
Iout + 7.8 mA
1.3026 A
2.6052 A
Iout + 5.2 mA
Iout + 10.4 mA
CC Load Effect
N5752A
N5772A
− 5.26 mA
− 5.5 mA
__________
__________
+ 5.26 mA
+ 5.5 mA
CC Source Effect
N5752A
N5772A
− 2.13 mA
− 2.26 mA
__________
__________
+ 2.13 mA
+ 2.26 mA
Test Description N5752A Setting N5772A Setting
Voltage Programming & Readback, Min Voltage 0 V, 0 A 0 V, 0 A
Voltage Programming & Readback, High Voltage 600 V, 0 A 600 V, 0 A
CV Load Effect, Source Effect, Ripple and Noise 600 V, 1.3 A 600 V, 2.6 A
Transient Response
200 V, from 0.13 A to 1.17 A 200 V, from 0.26 A to 2.34 A
Current Programming & Readback, Min Current 0 A, 600 V 0 A, 600 V
Current Programming & Readback, High Current 1.3 A, 600 V 2.6 A, 600 V
CC Load Effect, Source Effect 1.3 A, 600 V 2.6 A, 600 V
Load Requirements N5752A N5772A
Current shunt 0.1Ω 15 A 0.1Ω 15 A
Use fixed resistor instead of load modules 462Ω 1kW 231Ω 2kW
Fixed Resistor for CV Ripple and Noise 462Ω 1kW 231Ω 2kW
