Verification and Calibration Appendix B
Series N5700 User’s Guide 111
Test Record Form – Agilent N5751A and N5771A
Agilent N5751A and N5771A Report No _______________ Date __________________
Description Model Minimum Specs. Results Maximum Specs.
Voltage Programming & Readback
Minimum Voltage Vout
Front Panel Display Readback
High Voltage Vout
Front Panel Display Readback
Both
Both
Both
Both
− 150 mV
Vout − 300 mV
299.7 V
Vout − 600 mV
__________
__________
__________
__________
+ 150 mV
Vout + 300 mV
300.3 V
Vout + 600 mV
CV Load Effect Both − 32 mV __________ + 32 mV
CV Source Effect Both − 32 mV __________ + 32 mV
CV Ripple and Noise
peak-to-peak
rms
Both
Both
N/A
N/A
__________
__________
150 mV
20 mV
Transient Response
Voltage @ 2ms
Both
− 1 V
__________
+ 1 V
Current Programming & Readback
Minimum Current Iout
Front Panel Display Readback
High Current Iout
Front Panel Display Readback
N5751A
N5771A
N5751A
N5771A
N5751A
N5771A
N5751A
N5771A
− 2.5 mA
− 5 mA
Iout − 7.5 mA
Iout − 15 mA
2.495 A
4.99 A
Iout − 10 mA
Iout − 20 mA
__________
__________
__________
__________
__________
__________
__________
__________
+ 2.5 mA
+ 5 mA
Iout + 7.5 mA
Iout + 15 mA
2.505 A
5.01 A
Iout + 10 mA
Iout + 20 mA
CC Load Effect
N5751A
N5771A
− 5.5 mA
− 6 mA
__________
__________
+ 5.5 mA
+ 6 mA
CC Source Effect
N5751A
N5771A
− 2.25 mA
− 2.5 mA
__________
__________
+ 2.25 mA
+ 2.5 mA
Test Description N5751A Setting N5771A Setting
Voltage Programming & Readback, Min Voltage 0 V, 0 A 0 V, 0 A
Voltage Programming & Readback, High Voltage 300 V, 0 A 300 V, 0 A
CV Load Effect, Source Effect, Ripple and Noise 300 V, 2.5 A 300 V, 5 A
Transient Response
200 V, from 0.25 A to 2.25 A
200 V, from 0.5 A to 4.5 A
Current Programming & Readback, Min Current 0 A, 300 V 0 A, 300 V
Current Programming & Readback, High Current 2.5 A, 300 V 5 A, 300 V
CC Load Effect, Source Effect 2.5 A, 300 V 5 A, 300 V
Load Requirements N5751A N5771A
Current shunt 0.1Ω 15 A 0.1Ω 15 A
Use fixed resistor instead of load modules 120Ω 1kW 60Ω 2kW
Fixed Resistor for CV Ripple and Noise 120Ω 1kW 60Ω 2kW
