Appendix B Verification and Calibration
110 Series N5700 User’s Guide
Test Record Form – Agilent N5750A and N5770A
Agilent N5750A and N5770A Report No _______________ Date __________________
Description Model Minimum Specs. Results Maximum Specs.
Voltage Programming & Readback
Minimum Voltage Vout
Front Panel Display Readback
High Voltage Vout
Front Panel Display Readback
Both
Both
Both
Both
− 75 mV
Vout − 150 mV
149.85 V
Vout − 300 mV
__________
__________
__________
__________
+ 75 mV
Vout + 150 mV
150.15 V
Vout + 300 mV
CV Load Effect Both − 17 mV __________ + 17 mV
CV Source Effect Both − 17 mV __________ + 17 mV
CV Ripple and Noise
peak-to-peak
rms
Both
Both
N/A
N/A
__________
__________
100 mV
12 mV
Transient Response
Voltage @ 2ms
Both
− 750 mV
__________
+ 750 mV
Current Programming & Readback
Minimum Current Iout
Front Panel Display Readback
High Current Iout
Front Panel Display Readback
N5750A
N5770A
N5750A
N5770A
N5750A
N5770A
N5750A
N5770A
− 5 mA
− 10 mA
Iout − 15 mA
Iout − 30 mA
4.99 A
9.98 A
Iout − 20 mA
Iout − 40 mA
__________
__________
__________
__________
__________
__________
__________
__________
+ 5 mA
+ 10 mA
Iout + 15 mA
Iout + 30 mA
5.01 A
10.02 A
Iout + 20 mA
Iout + 40 mA
CC Load Effect
N5750A
N5770A
− 6 mA
− 7 mA
__________
__________
+ 6 mA
+ 7 mA
CC Source Effect
N5750A
N5770A
− 2.5 mA
− 3 mA
__________
__________
+ 2.5 mA
+ 3 mA
Test Description N5750A Setting N5770A Setting
Voltage Programming & Readback, Min Voltage 0 V, 0 A 0 V, 0 A
Voltage Programming & Readback, High Voltage 150 V, 0 A 150 V, 0 A
CV Load Effect, Source Effect, Ripple and Noise 150 V, 5 A 150 V, 10 A
Transient Response 150 V, from 0.5 A to 4.5 A 150 V, from 1 A to 9 A
Current Programming & Readback, Min Current 0 A, 150 V 0 A, 150 V
Current Programming & Readback, High Current 5 A, 150 V 10 A, 150 V
CC Load Effect, Source Effect 5 A, 150 V 10 A, 150 V
Load Requirements N5750A N5770A
Current shunt 0.1Ω 15 A 0.1Ω 15 A
Agilent N3300 Electronic load modules 2 – N3305A 3 – N3305A
Fixed Resistor for CV Ripple and Noise 30.0Ω 1kW 15.0Ω 2kW
