Appendix B Verification and Calibration
106 Series N5700 User’s Guide
Test Record Form – Agilent N5746A and N5766A
Agilent N5746A and N5766A Report No _______________ Date __________________
Description Model Minimum Specs. Results Maximum Specs.
Voltage Programming & Readback
Minimum Voltage Vout
Front Panel Display Readback
High Voltage Vout
Front Panel Display Readback
Both
Both
Both
Both
− 20 mV
Vout − 40 mV
39.96 V
Vout − 80 mV
__________
__________
__________
__________
+ 20 mV
Vout + 40 mV
40.04 V
Vout + 80 mV
CV Load Effect Both − 6 mV __________ + 6 mV
CV Source Effect Both − 6 mV __________ + 6 mV
CV Ripple and Noise
peak-to-peak
rms
Both
Both
N/A
N/A
__________
__________
60 mV
8 mV
Transient Response
Voltage @ 1ms
Both
− 200 mV
__________
+ 200 mV
Current Programming & Readback
Minimum Current Iout
Front Panel Display Readback
High Current Iout
Front Panel Display Readback
N5746A
N5766A
N5746A
N5766A
N5746A
N5766A
N5746A
N5766A
− 19 mA
− 38 mA
Iout − 57 mA
Iout − 114 mA
18.962 A
37.924 A
Iout − 76 mA
Iout − 152 mA
__________
__________
__________
__________
__________
__________
__________
__________
+ 19 mA
+ 38 mA
Iout + 57 mA
Iout + 114 mA
19.038 A
38.076 A
Iout + 76 mA
Iout + 152 mA
CC Load Effect
N5746A
N5766A
− 8.8 mA
− 12.6 mA
__________
__________
+ 8.8 mA
+ 12.6 mA
CC Source Effect
N5746A
N5766A
− 3.9 mA
− 5.8 mA
__________
__________
+ 3.9 mA
+ 5.8 mA
Test Description N5746A Setting N5766A Setting
Voltage Programming & Readback, Min Voltage 0 V, 0 A 0 V, 0 A
Voltage Programming & Readback, High Voltage 40 V, 0 A 40 V, 0 A
CV Load Effect, Source Effect, Ripple and Noise 40 V, 19 A 40 V, 38 A
Transient Response 40 V, from 1.9 A to 17.1 A 40 V, from 3.8 A to 34.2 A
Current Programming & Readback, Min Current 0 A, 40 V 0 A, 40 V
Current Programming & Readback, High Current 19 A, 40 V 38 A, 40 V
CC Load Effect, Source Effect 19 A, 40 V 38 A, 40 V
Load Requirements N5746A N5766A
Current shunt 0.01Ω 100 A 0.01Ω 100 A
Agilent N3300 Electronic load modules 2 – N3305A 3 – N3305A
Fixed Resistor for CV Ripple and Noise 2.11Ω 1kW 1.05Ω 2kW
