User’s Guide 89
U3042AE12 Safety and Regulatory Information
Compliance with German Noise Requirements
This is to declare that this instrument is in conformance with the German Regulation on
Noise Declaration for Machines (Laermangabe nach der Maschinenlaermrerordnung-3.
GSGV Deutschland).
EMC Information
Complies with European EMC Directive 89/336/EEC, amended by 93/68/EEC
• IEC/EN 61326
This product complies with the radiated electromagnetic field immunity requirement in
IEC/EN 61326 using performance criterion B. Degradation of some product specifications
can occur in the presence of ambient electromagnetic fields. The product self-recovers and
operates as specified when the ambient field is removed.
• CISPR Pub 11 Group 1, class A
• AS/NZS CISPR 11:2002
• This ISM device complies with Canadian ICES-001.
Cet appareil ISM est conforme a la norme NMB du Canada.
Safety Information
Complies with European Low Voltage Directive 2006/95/EC
• IEC/EN 61010-1:2001
• Canada: CSA C22.2 No. 61010-4
• USA: UL Std No. 61010-1 (2nd Edition)
Acoustic Noise Emission/Geraeuschemission
LpA<70 dB Lpa<70 dB
Operator Position am Arbeitsplatz
Normal Operation normaler Betrieb
per ISO 7779 nach DIN 45635 t. 19
