User’s Guide 81
U3042AE12 Service Information
Service Information
Refer to “Contacting Agilent” on page 94.
WARNING No operator serviceable parts inside. Refer servicing to qualified
personnel. To prevent electrical shock do not remove covers.
WARNING These servicing instructions are for use by qualified personnel only.
To avoid electrical shock, do not perform any servicing unless you
are qualified to do so.
Replaceable Parts
Special options are built to order, so long lead times may be encountered when ordering
replacement parts..
Description Agilent
Part Number
Test set I/’O Cable 8120-6818
RF Cable, Semi-rigid Z5623-20418
RF Cable, Semi-rigid Z5623-20419
Port 1 SOURCE OUT U3042-20031
Port 1 CPLR THRU U3042-20032
Port 1 CPLR ARM U3042-20029
Port 1 RCVR A IN U3042-20030
Port 3 SOURCE OUT U3042-20035
Port 3 CPLR ARM U3042-20033
Port 3 RCVR C IN U3042-20034
Port 3 CPLR THRU U3042-20036
Port 4 CPLR ARM U3042-20037
Port 4 RCVR D IN U3042-20038
Port 4 SOURCE OUT U3042-20039
Port 4 CPLR THRU U3042-20040
Port 2 CPLR ARM U3042-20041
Port 2 SOURCE OUT U3042-20043
Port 2 RCVR B IN U3042-20042
Port 2 CPLR THRU U3042-20044
Screw 0515-2317
PNA-X Test Set Rear Lock Feet (right) N5242-20138
PNA-X Test Set Rear Lock Feet (left) N5242-20139
