U3042AE12 Test Set I/O Interface Commands
Table 18 PNA Port 1 and Test Set Ports 6, 10 and 14
Address Decimal Data Description
16 D0 - D3 Controls SW200; Source to PNA Port 2 or Test Set Port 6, 10 and 14.
16 D4 - D7 Controls SW201; Receiver to PNA Port 2 or Test Set Port 6, 10 and 14.
Test Set I/O Data Bit D0D1D2D3D4D5D6D7
Data Bit Decimal Equivalent 1248163264128
Table 19 Address and Data for Port 6, 10 and 14
Address Data Description Port LED’s
16 17 Selects the Port 2 as the Source and Receiver port. Port 6, 10
and 14 terminated with a 50 Ω switch load.
All Off
16 18 Selects the PNA Port 2 as the Receiver and Port 6 as the
Source. Ports 10 and 14 terminated with a 50 Ω switch load.
Port 6 S ON
16 35 Selects the Port 2 as the Source Port. Port 6 as the Receiver.
Ports 10 and 14 terminated with a 50 Ω switch load.
Port 6 R ON
16 34 Selects the Port 6 as the Source and Receiver port. Port 2, 10
and 14 terminated with a 50 Ω switch load.
Port 6 R ON
Port 6 S ON
16 65 Port 2 as the Source and Port 10 as the Receiver Port. Port
Ports 6 and 14 terminated with a 50 Ω switch load.
Port 10 R ON
16 20 Port 2 as the Receiver and Port 10 as the Source. Port 6 and
14 terminated with a 50 Ω switch load.
Port 10 S ON
16 68 Port 10 as the Receiver and Source. Port 2, 6 and 14
terminated with a 50 Ω switch load.
Port 10 R ON
Port 10 S ON
16 24 Port 10 as the Source and Port 2 as the Receiver. Port 6 and
10 terminated with a 50 Ω switch load.
Port 14 S ON
16 129 Port 2 as the Source and Port 14 as the Receiver. Port 6 and
10 terminated with a 50 Ω switch load.
Port 14 R ON
16 68 Port 14 as the Receiver and Source. Port 2, 6 and 10
terminated with a 50 Ω switch load.
Port 14 R ON
Port 14 S ON
