User’s Guide 53
U3042AE12 Controlling the Test Set with N5242A or N5230C
OK:
Applies the settings and closes the dialog box.
Cancel:
Does not apply changes that were made and closes the dialog box.
NOTE U3042AE12 Test Set I/O Commands can be found in “Test Set I/O Interface
Commands” on page 61. The Address and Data commands can be entered into
the Test Set I/O control.
N5242A or N5230C GPIB Control
The GPIB Command Processor feature allows you to send remote commands and data to
the PNA rear-panel GPIB connector and test set I/O connector. More information
regarding the GPIB Command Processor can be found in the PNA Series Network
Analyzer Help System Menu.
•Overview
• How to Access GPIB Command Processor
• GPIB Command Processor Console
Overview of the GPIB Control
The GPIB Command Processor allows you to send address and data to control an external
test set, without needing to create a remote program. The user is required to manually
input address and data using the GPIB Command Processor Console in the PNA Series
Network Analyzer Help System Menu.
• GPIB Command Processor settings can not be saved or recalled.
• Address and data can be written to the GPIB Command Processor and read from the
GPIB Command Processor.
