40 User’s Guide
U3042AE12 Controlling the Test Set with N5242A or N5230C
Controlling the Test Set with N5242A or N5230C
This section will describe how to setup and operate the U3042AE12 Multiport Test Set
with the N5242A or N5230C. Both will be referred to as the PNA-X in this section.
The U3042AE12 Multiport Test Set is considered a “slave” instrument. A PNA-X must be
used to control the Test Set. There are three methods to control the Test Set. Multiport
mode is recommended due to calibration and ease of use.
• PNA Multiport Mode firmware revision:
N5242A Option 551≥ A.08.04.07
N5230C Option 551 ≥ A.08.04.10
The following test set file must be installed into network analyzer file directory:
c:\Program Files\Agilent\Network Analyzer\testsets
4-Port PNA-L requires test set: u3042ae12_p4.tsx
4-Port PNA-X requires test set: u3042ae12_pna_p4.tsx
• PNA Interface Control
• PNA GPIB Command Processor
Visit our website for firmware revision and
downloads.http://na.tm.agilent.com/pna/firmware/firmware.htm
You may als o refer to “Installing New Firmware” on page 18 in this manual.
PNA Multiport Mode for Option 551
The PNA multiport mode selects the test set file that will enable the PNA to control the
Test Set. The PNA-X multiport mode allows you to complete a N-Port calibration using the
Cal Wizard application in the PNA. Refer to the PNA Help system for more information.
