U3042AE12 System Setup with N5242A
N5242A RF Interface Cable Connections
Figure 29 on page 39 illustrates the setup configuration of the U3042AE12 Multiport Test
Set and how it should be configured to the PNA-X. The cables have been supplied with
Option 042.
1. Connect the RF interconnect cables from the PNA-X to the Test Set in the order listed.
As you are connecting each cable, torque to 8 in-lb. The longer, straight end of each
cable is connected to the test set. Refer to Table 11 and Figure 29 on page 39.
CAUTION Over torque will cause damage to the test set and may cause connectors to
spin or become loose.
Table 11 N5242A RF Interface Cable Connection (Option 042)
Numeric
Order
RF Cables From PNA-X To Test Set
1 U3042-20031 Port 1 SOURCE OUT Port 5 SOURCE IN
2 U3042-20032 Port 1 CPLR THRU Port 5 CPLR THRU
3 U3042-20029 Port 1 CPLR ARM Port 5 CPLR ARM
4 U3042-20030 Port 1 RCVR A IN Port 5 RCVR OUT
5 U3042-20035 Port 3 SOURCE OUT Port 6 SOURCE IN
6 U3042-20033 Port 3 CPLR ARM Port 6 CPLR ARM
7 U3042-20034 Port 3 RCVR C IN Port 6 RCVR OUT
8 U3042-20036 Port 3 CPLR THRU Port 6 CPLR THRU
9 U3042-20039 Port 4 SOURCE OUT Port 7 SOURCE IN
10 U3042-20037 Port 4 CPLR ARM Port 7 CPLR ARM
11 U3042-20038 Port 4 RCVR D IN Port 7 RCVR OUT
12 U3042-20040 Port 4 CPLR THRU Port 7 CPLR THRU
13 U3042-20041 Port 2 CPLR ARM Port 8 CPLR ARM
14 U3042-20044 Port 2 CPLR THRU Port 8 CPLR THRU
15 U3042-20043 Port 2 SOURCE OUT Port 8 SOURCE IN
16 U3042-20042 Port 2 RCVR B IN Port 8 RCVR OUT
