User’s Guide 13
U3042AE12 Front and Rear Panel Features
Available Fuses
• Fuse (F 5 A/250V, 2110-0709) U.L. listed and CSA certified
WARNING For continued protection against fire hazard replace line fuse only
with same type and rating:
• Fuse 5A/250V, Part Number 2110-0709
The use of other fuses or material is prohibited.
Figure 5 Line Fuse
CAUTION This instrument has autoranging line voltage input; be sure the supply
voltage is within the specified range.
