8 User’s Guide
U3042AE12 General Specifications
Dimensions and Space Requirements
Standard installation of the U3042AE12 and PNA includes configuration and installation
on a customer provided lab bench or table top of adequate size and strength.
Table 4 System Dimensions
Item Weight
Required Bench Top Dimension:
Clearance above the bench 43 cm (17 in)
Width 127 cm (50 in)
Depth 102 cm (40 in)
Weight 55 kg (110 lb)
Table 5 Instrument Dimensions
Model Weight Height Width Depth
N5242A
37 kg
(82 lb, ±0.5 lb)
26.67 cm
(10.5 in)
42.5 cm
(16.57 in)
55.8 cm
(21.97 in)
N5230A/C
29.7 kg
(65.5 lb, ±0.5 lb)
27.9 cm
(11 in)
48.3 cm
(19 in)
50 cm
(19.7 in)
U3042AE12 11.4 kg (25 lb) 19.1 cm
(7.5 in)
42.5 cm
(16.7 in)
43.2 cm
(17 in)
