User’s Guide 5
U3042AE12 Verifying the Shipment
Verifying the Shipment
Inspect the shipping container. If the container or packing material is damaged, it should
be kept until the contents of the shipment have been checked mechanically and electrically.
If there is physical damage refer to “Contacting Agilent” on page 94. Keep the damaged
shipping materials (if any) for inspection by the carrier and an Agilent Technologies
representative. Table 1 contains the accessories shipped with your U3042AE12.
Table1 Content List
Agilent
Part Number
Description Qty
Common to the following Options
9320-6636 Functional Test Certificate 1
9320-0333 Envelope-Cal Certificate 1
5023-0132 Locking Feet 1
8120-6818 Test Set I/O Cable 1
U3042-90001 User’s Guide 1
Option 016 (Cable-set for PNA-L)
Z5623-20418 RF Cable Semi-rigid 8
Z5623-20419 RF Cable Semi-rigid 8
Option 042 (Cable-set for PNA-X)
U3042-20031 RF Cable Semi-rigid 1
U3042-20032 RF Cable Semi-rigid 1
U3042-20029 RF Cable Semi-rigid 1
U3042-20030 RF Cable Semi-rigid 1
U3042-20035 RF Cable Semi-rigid 1
U3042-20033 RF Cable Semi-rigid 1
U3042-20034 RF Cable Semi-rigid 1
U3042-20036 RF Cable Semi-rigid 1
U3042-20037 RF Cable Semi-rigid 1
U3042-20038 RF Cable Semi-rigid 1
U3042-20039 RF Cable Semi-rigid 1
U3042-20040 RF Cable Semi-rigid 1
U3042-20041 RF Cable Semi-rigid 1
U3042-20043 RF Cable Semi-rigid 1
U3042-20044 RF Cable Semi-rigid 1
0515-2317 Screw 2
N5242-20138 Rear Lock Feet (right) 1
N5242-20139 Rear Lock Feet (left) 1
