User’s Guide 3
U3042AE12 Description
Description
The Agilent U3042AE12 Multiport Test Set is a 12-Port solid-state extension test set.
When combined with a 4-Port N5230A/C PNA-L or N5242A PNA-X Network Analyzer, the
U3042AE12 provides a complete solution for 16-Port full crossbar measurements.
The test set is directly controlled by the network analyzer, no external personal computer
or software is required.
The N5230A/C PNA-L and N5242A PNA-X Network Analyzer’s will be referred to
throughout this document as the PNA-L and the PNA-X. PNA refers to both PNA-L or
PNA-X.
Network Analyzer Requirement
• The Network Analyzer requires Option 551 (N-Port error correction and measurement
capability).
• The N5230A/C PNA-L requires Option 245, 145, 246 or 146 to provide the test set
interface connections and requires test set file u3042ae12_p4.tsx
• The N5242A PNA-X requires Option 400 to provide the test set interface connections
and requires test set file u3042ae12_pnax_p4.tsx.
More PNA information is available on the following websites:
• Documentation - http://www.agilent.com/find/pna
• Network Analyzer Firmware - http://na.tm.agilent.com/pna/firmware/firmware.htm
Refer to “Installing New Firmware” on page 18.
• U3042AE12 Test Set Files - http://na.tm.agilent.com/multiport. (see test set files link)
