94 User’s Guide
U3042AE12 Contacting Agilent
Contacting Agilent
Assistance with test and measurement needs, and information on finding a local Agilent
office are available on the Internet at:
http://www.agilent.com/find/assist
You can also purchase accessories or documentation items on the Internet at:
http://www.agilent.com/find
If you do not have access to the Internet, contact your field engineer.
NOTE In any correspondence or telephone conversation, refer to the product by its
model number and full serial number. With this information, the Agilent
representative can determine the warranty status of your unit.
