User guide
Table Of Contents
- 1 Getting Started
- 2 N4962A System Overview
- 3 System Details and Performance Specifications
- 4 Operation
- 5 Remote GPIB Interface
- 6 Returning the N4962A Serial BERT to Agilent Technologies

System Details and Performance Specifications
Serial BERT 12.5 Gb/s User Guide 23
3 System Details and Performance
Specifications
Specifications describe the instrument’s warranted performance. Non-
warranted values are stated as typical. All specifications are valid in a range
from 10°C to 40°C ambient temperature after a 30 minute warm-up phase. If
not otherwise stated, all unused RF inputs and outputs must be terminated
with the included 50 Ω-terminated connectors.
3.1 General
Table 2. General and mechanical parameters of N4962A
Operating Temperature
+10°C to +40°C
Storage Temperature
–40°C to +70°C
Power Requirements
4
2 W External AC Adaptor (included)
• 100 to 240 VAC, 47 to 63 Hz
Physical Dimensions
Width: 254 mm (10 in), Height: 63.5 mm (2.5 in), Depth: 254 mm (10 in)
Weight
3.4 kg (7.5 lbs)
EMC
Complies with European EMC Directive 2004/108/EC
• IEC/EN 61326-1
• CISPR Pub 11 Group 1, class A
• AS/NZS CISPR 11
• ICES/NMB-001
This ISM device complies with Canadian ICES
-001.
Cet appareil ISM est conforme a la norme NMB
-001 du Canada.
