Page 5-51XTRAEDIT CONFIGURATION
Line 1 Page 1
Line 2 Page 1
Line 3 Page 1
Line 4 Page 1
Line 5 Page 1
Line 6 Page 1
Line 7 Page 1
Line 8 Page 1
Line 9 Page 1
Line 10 Page 1
Line 11 Page 1
Line 12 Page 1
Line 13 Page 1
Line 14 Page 1
Line 15 Page 1
Line 16 Page 1
Line 17 Page 1
Line 18 Page 1
Line 19 Page 1
Line 20 Page 1
Line 21 Page 1
Line 22 Page 1
Line 23 Page 1
Line 24 Page 1
Line 25 Page 1
Line 26 Page 1
Line 27 Page 1
Line 28 Page 1
Line 29 Page 1
Line 30 Page 1
Line 31 Page 1
Line 32 Page 1
Line 33 Page 1
Line 34 Page 1
Line 35 Page 1
Line 36 Page 1
Line 37 Page 1
Line 38 Page 1
Line 39 Page 1
Line 40 Page 1
Line 41 Page 1
Line 42 Page 1
Line 43 Page 1
Line 44 Page 1
Line 45 Page 1
Line 46 Page 1
Line 47 Page 1
Line 48 Page 1
Line 49 Page 1
Line 50 Page 1
Line 1 Page 2
Line 2 Page 2
Line 3 Page 2
Line 4 Page 2
Line 5 Page 2
Line 6 Page 2
Line 7 Page 2
Line 8 Page 2
Line 9 Page 2
Line 10 Page 2
Line 11 Page 2
Line 12 Page 2
Line 13 Page 2
Line 14 Page 2
Line 15 Page 2
Line 16 Page 2
Line 17 Page 2
Line 18 Page 2
Line 19 Page 2
Line 20 Page 2
Line 21 Page 2
Line 22 Page 2
Line 23 Page 2
Line 24 Page 2
Line 25 Page 2
Line 26 Page 2
Line 27 Page 2
Line 28 Page 2
Line 29 Page 2
Line 30 Page 2
Line 31 Page 2
Line 32 Page 2
Line 33 Page 2
Line 34 Page 2
Line 35 Page 2
Line 36 Page 2
Line 37 Page 2
Line 38 Page 2
Line 39 Page 2
Line 40 Page 2
Line 41 Page 2
Line 42 Page 2
Line 43 Page 2
Line 44 Page 2
Line 45 Page 2
Line 46 Page 2
Line 47 Page 2
Line 48 Page 2
Line 49 Page 2
Line 50 Page 2
The resulting output should look like this:
Duplex
Duplex gives the user the options of Simplex printing, Side-to-Side duplex
printing or Head-to-Toe duplex printing. The default value is Simplex.
Simplex is equivalent to the XES Duplex Stop command, Side-to-Side is
equivalent to the Duplex Start command, and Head-to-Toe is equivalent
to the Duplex Invert Start command.
Page Length (Portrait, Landscape)
Page Length enables the user to specify a page length between 0 and 14
inches. The value can be entered in inches, 1/300 inches or 1/60 inches,
depending upon the setting of Measurement Setting for Entries under the
Preferences menu. If inches, the user can enter a value between 1.000
and 14.000. In 1/300 inches, the user can enter an integer value between
300 and 4200. In 1/60 inches, the user can enter an integer value between
60 and 840. The default value for portrait is 3300 (300ths inch). The
default for landscape is 2550.
The Page Length option is equivalent to the H parameter of the XES
Margins and Margins Double Page commands.
