User’s ManualPage 4-6
character.
It makes no difference to the XLi which emulation name follows
EMULATE. Any emulation except for the three below will cause the
XLi to enter pass-through mode. When the XLi receives one of the
following commands, it will change back to XES-to-PCL5 translation:
=MCK= EMULATE/2700/ENDd
=MCK= EMULATE/XDCS/ENDd
=MCK= EMULATE/XES/ENDd
A space is required immediately after the command sequence =MCK=.
An emulation change is always temporary, and will revert back to the
default mode after a power off/on.
Note: Changing emulation modes may cause the printer to erase all
downloaded fonts from memory. In such cases, the user will need to
download the fonts to the printer after executing an emulation change.
Alternatively, the printer can be configured with context saving enabled.
The X/Li also supports the =MCK= commands SAVE and RESTORE.
The =MCK= command NVRAM results in no operation.
=MCK= SAVE/ENDd
will save the current emulation (either PCL or pass-through) to the XLis
FLASH memory until the printer is powered off.
=MCK= RESTORE/ENDd
will change the emulation to the emulation stored using the SAVE
command above.
=MCK= RESET/ENDd
will change the emulation to the default power-on emulation.
