- EMC Measurement Application Measurement Guide
- Table of Contents
- 1 EMC Measurements
- 2 Conducted Emissions Measurements
- 3 Radiated Emissions Measurements
- A: Line Impedance Stabilization Networks (LISN)
- B: Antenna Factors
- C: Basic Electrical Relationships
- D: Detectors Used in EMI Measurements
- Glossary of Acronyms and Definitions
7
EMC Measurements
1 EMC Measurements
The EMC measurement application enables you to perform precompliance conducted
and radiated emissions tests to both commercial and MIL-STD requirements. It
provides better sensitivity, accuracy and reduces test margins, across the X-Series
signal analyzers, so you can make more precise measurement. The wide range of
features enables you to:
• Set up frequency ranges, gains, bandwidths and dwell time
• Scan a frequency range and display the results in log or linear format, search for
signals, measure the peak, quasi-peak and average values of the signal and place
the results in a table
• Use the Signal List feature to mark and delete unwanted signals, leaving only those
of interest
• Identify signals that fail the regulatory agency limit
