:SBUS<N>:CAN:TRIGger
Command :SBUS<N>:CAN:TRIGger <condition>
<condition> ::= {SOF | DATA | ERRor | IDData | IDRemote | ALLerrors
| OVERload | ACKerror | MESSage | MSIGnal}
The :SBUS<N>:CAN:TRIGger command sets the CAN trigger on condition:
• SOF - will trigger on the Start of Frame (SOF) bit of a Data frame,
Remote Transfer Request (RTR) frame, or an Overload frame.
• DATA - will trigger on CAN Data frames matching the specified Id,
Data, and the DLC (Data length code).
• ERRor — will trigger on CAN Error frame.
• IDData — will trigger on CAN frames matching the specified Id of a
Data frame.
• IDRemote — will trigger on CAN frames matching the specified Id of a
Remote frame.
• ALLerrors — will trigger on CAN active error frames and unknown bus
conditions.
• OVERload — will trigger on CAN overload frames.
• ACKerror — will trigger on a data or remote frame acknowledge bit that
is recessive.
The table below shows the programming parameter and the corresponding
front-panel softkey selection:
NOTE
You must set the proper :SBUS<N>:MODE, :SBUS<N>:CAN:TRIGger, and
:SBUS<N>:CAN:TRIGger:PATTern:ID:MODE before setting any other trigger values.
Remote <condition> parameter Front-panel Trigger on: softkey selection
(softkey text - softkey popup text)
SOF SOF - Start of Frame
DATA ID & Data - Data Frame ID and Data
ERRor Error - Error frame
IDData ID & ~RTR - Data Frame ID (~RTR)
IDRemote ID & RTR - Remote Frame ID (RTR)
ALLerrors All Errors - All Errors
