770 Agilent Infiniium 9000 Series Oscilloscopes Programmer's Reference
27 Root Level Commands
:MTER?
(Mask Test Event Register)
Query
:MTER?
The :MTER? query returns the value stored in the Mask Test Event
Register. The bits stored in the register have the following meanings:
The Mask Test Event Register is read and cleared by the MTER? query.
The register output is enabled or disabled using the mask value supplied
with the MTEE command.
Returned Format 0-63 decimal value.
Bit 0 Mask Test Complete bit is set whenever the mask test is complete.
Bit 1 Mask Test Fail bit is set whenever the mask test failed.
Bit 2 Mask Low Amplitude bit is set whenever the signal is below the mask
amplitude.
Bit 3 Mask High Amplitude bit is set whenever the signal is above the mask
amplitude.
Bit 4 Mask Align Complete bit is set whenever the mask align is complete.
Bit 5 Mask Align Fail bit is set whenever the mask align failed.
NOTE
Disabled Mask Test Event Register Bits Respond, but Do Not Generate a Summary
Bit
Mask Test Event Register bits that are not enabled still respond to their corresponding
conditions (that is, they are set if the corresponding event occurs). However, because they
are not enabled, they do not generate a summary bit in the Operation Status Register.
