592 Agilent Infiniium 9000 Series Oscilloscopes Programmer's Reference
25 Measure Commands
:MEASure:NOISe:ALL?
Query
:MEASure:NOISe:ALL? {ZERO | ONE}
The :MEASure:NOISe:ALL? query returns the NOISe measurement results
for the specified level. These values are returned as comma separated
values using the following format:
Returned Format
[:MEASure:NOISe:ALL<space>]
TI(<format>),<result>,<state>,
RN(<format>),<result>,<state>,
DI(<format>),<result>,<state>,
PI(<format>),<result>,<state>,
ABUI(<format>),<result>,<state>,
BUI(<format>),<result>,<state>,
ISI(<format>),<result>,<state>,
Count,<number_of_bits>,<state>,
Level,<nominal_level>,<state>,
Eye Height(<format>),<result>,<state>,<NL>
<space> White space (ASCII 32) character.
<format> The format value tells you something about how the measurement is made.
For instance, TI(1E- 12) means that the TI measurement was derived using
a bit error rate of 1E- 12. A format of (rms) means the measurement is a
root-mean- square measurement. A format of (dd) means the measurement
uses a dual-Dirac delta model to derive the measurement. A format of
(pp) means the measurement is a peak- to- peak measurement.
<result> The measured results for the NOISe measurements. A value of 9.99999E+37
means that the oscilloscope was unable to make the measurement.
<state> The measurement result state. See Table 20 for a list of values and
descriptions of the result state value.
<number_of_
bits>
The number of waveform bits that have been measured.
NOTE
This command is only available when the EZJIT Complete software is installed.
NOTE
Whether some of these values are included or not depends on the setting of
:MEASure:NOISe:METHod and :MEASure:NOISe:REPort.
For example, when :MEASure:NOISe:REPort or :MEASure:NOISe:METHod is SPECtral, the
BUI and ABUI values are not returned, and there are two PI values (one "rms" and one
"dd").
