420 Agilent Infiniium 9000 Series Oscilloscopes Programmer's Reference
23 Marker Commands
:MARKer:CURSor?
Query :MARKer:CURSor? {DELTa | STARt | STOP}
The :MARKer:CURSor? query returns the time and current measurement
unit values of the specified marker (if markers are in Track Waveforms
mode) as an ordered pair of time and measurement unit values.
• If DELTA is specified, the value of delta Y and delta X are returned.
• If START is specified, marker A's x- to- y positions are returned.
• If STOP is specified, marker B's x-to- y positions are returned.
Returned Format
[:MARKer:CURSor] {DELTa | STARt | STOP}
{<Ax, Ay> | <Bx, By> | <deltaX, deltaY>}<NL>
Example This example returns the current position of the X cursor and
measurement unit marker 1 to the string variable, strPosition. The
program then prints the contents of the variable to the computer's screen.
Dim strPosition As String ' Dimension variable.
myScope.WriteString ":MARKER:CURSOR? START"
strPosition = myScope.ReadString
Debug.Print strPosition
CAUTION
The :MARKer:CURSor? query may change marker mode and results.
In Track Waveforms mode, use :MARKer:CURSor? to track the position of the
waveform. In Manual Markers and Track Measurements Markers modes, use other
marker queries, such as the X1Position? and X2Position?, and VSTArt? and VSTOp?
queries.
If you use :MARKer:CURSor? when the oscilloscope is in either Manual Markers or
Track Measurements Markers modes, it will put the oscilloscope in Track
Waveforms mode, regardless of the mode previously selected. In addition,
measurement results may not be what you expected. In addition, measurement
results may not be what you expected.
