Agilent Infiniium 9000 Series Oscilloscopes
Programmer's Reference
23
Marker Commands
:MARKer:CURSor? 420
:MARKer:MEASurement:MEASurement 421
:MARKer:MODE 422
:MARKer:TSTArt 423
:MARKer:TSTOp 424
:MARKer:VSTArt 425
:MARKer:VSTOp 426
:MARKer:X1Position 427
:MARKer:X2Position 428
:MARKer:X1Y1source 429
:MARKer:X2Y2source 431
:MARKer:XDELta? 433
:MARKer:Y1Position 434
:MARKer:Y2Position 435
:MARKer:YDELta? 436
The commands in the MARKer subsystem specify and query the settings of
the time markers (X axis) and current measurement unit markers (volts,
amps, and watts for the Y axis). You typically set the Y- axis measurement
units using the :CHANnel:UNITs command.
NOTE
Guidelines for Using Queries in Marker Modes
In Track Waveforms mode, use :MARKer:CURSor? to track the position of the waveform. In
Manual Markers and Track Measurements Markers modes, use other queries, such as the
X1Position? and X2Position?, and VSTArt? and VSTOp? queries. If you use
:MARKer:CURSor? when the oscilloscope is in either Manual Markers or Track
Measurements Markers modes, it will put the oscilloscope in Track Waveforms mode,
regardless of the mode previously selected. In addition, measurement results may not be
what you expected.
