What's New 1
Agilent Infiniium 9000 Series Oscilloscopes Programmer's Reference 41
What's New in Version 3.10
New command descriptions for Version 3.10 of the Infiniium 9000 Series
oscilloscope software appear below.
New Commands
Changed
Commands
Command Description
:ACQuire:BANDwidth (see
page 150)
Changes the bandwidth frequency control for the acquisition
system.
:DISPlay:STATus:COL (see
page 315)
Used to position the real time eye and InfiniiScan Zone Trigger
status labels.
:DISPlay:STATus:ROW (see
page 316)
Used to position the real time eye and InfiniiScan Zone Trigger
status labels.
:MEASure:DDPWS (see
page 1159)
For measuring Data Dependent Pulse Width Shrinkage.
:MEASure:EDGE (see
page 539)
For measuring the edge time relative to the reference location.
:MEASure:JITTer:SPECtrum:V
ERTical:TYPE (see page 579)
Lets you select either a LINear or a LOGarithmic vertical scale
for the jitter spectrum plot.
:MEASure:RJDJ:APLength?
(see page 631)
Returns the determined RjDj pattern length.
:SPRocessing:CTLequalizer:N
UMPoles (see page 838)
Selects either a 2 Pole or 3 Pole Continuous Time Linear
Equalization.
:SPRocessing:CTLequalizer:P3
(see page 841)
Sets the Pole 3 frequency for the Continuous Time Linear
Equalization.
Command Description
:ACQuire:INTerpolate (see
page 155)
The INT1, INT2, INT4, INT8, INT16 options have been added for
specifying the 1, 2, 4, 8, or 16 point Sin(x)/x interpolation ratios.
:MEASure:RJDJ:BER (see
page 633)
You can now set J2 and J9 jitter BER levels.
:MEASure:VRMS (see
page 735)
The VOLT and DBM parameters have been added for specifying
the measurement units.
:MEASure:WINDow (see
page 742)
The short form of the command was changed from :MEAS:WIN
to :MEAS:WIND.
