40 Agilent Infiniium 9000 Series Oscilloscopes Programmer's Reference
1 What's New
What's New in Version 3.11
New command descriptions for Version 3.11 of the Infiniium 9000 Series
oscilloscope software appear below.
New Commands
Changed
Commands
Command Description
:CHANnel<N>:ISIM:PEXTracti
on (see page 211)
Selects a channel's InfiniiSim port extraction.
:CHANnel<N>:PROBe:ACCal
(see page 218)
Sets the type of AC response probe calibration to use.
:CHANnel<N>:PROBe:PRECpr
obe:BANDwidth (see
page 236)
Specifies how the limit of PrecisionProbe or PrecisionCable
correction/boosting is determined..
:CHANnel<N>:PROBe:PRECpr
obe:CALibration (see
page 237)
Specifies the name of the PrecisionProbe or PrecisionCable
calibration to use for the specified channel and probe.
:CHANnel<N>:PROBe:PRECpr
obe:MODE (see page 238)
Selects between PrecisionProbe or PrecisionCable AC response
probe calibration.
:CHANnel<N>:PROBe:PRECpr
obe:ZSRC (see page 239)
Specifies how PrecisionProbe characterizes the time domain
and frequency domain response.
:MEASure:HISTogram:MODE
(see page 563)
Returns the measurement histogram's Mode value.
Command Description
:BUS:B<N>:TYPE (see
page 172)
The MPHY protocol type has been added for the MIPI M-PHY
serial decode selection.
:FUNCtion<F>:FFT:WINDow
(see page 338)
The HAMMing window mode is now a valid selection.
:MEASure:JITTer:SPECtrum:W
INDow (see page 580)
The HAMMing window mode is now a valid selection.
