What's New 1
Agilent Infiniium 9000 Series Oscilloscopes Programmer's Reference 37
What's New in Version 3.50
New command descriptions for Version 3.50 of the Infiniium 9000 Series
oscilloscope software appear below.
New Commands
Command Description
:CHANnel<N>:PROBe:AUToze
ro (see page 220)
Initiates the N2893A probe's auto degauss/ offset cal.
:CHANnel<N>:PROBe:HEAD:
VTERm (see page 233)
Sets the termination voltage for the N5444A probe head.
:CHANnel<N>:PROBe:MODE
(see page 235)
Sets the N2750A probe's InfiniiMode configuration.
:FUNCtion<F>:MTRend (see
page 354)
New Meas Trend math function.
:FUNCtion<F>:MHIStogram
(see page 352)
New Meas Histogram math function.
:LISTer Commands (see
page 415)
For displaying and retrieving data from the serial decode listings.
:MEASure:HISTogram:RESolut
ion (see page 566)
The bin width value of one bar in the histogram.
:MEASure:NOISe (see
page 591)
Adds a Noise measurement to the oscilloscope display (like
Measure > Data > Noise from the front panel) or gets the
measured noise value.
:MEASure:NOISe:ALL (see
page 592)
Returns the NOISe measurement results for the "zeros" or
"ones" level.
:MEASure:NOISe:BANDwidth
(see page 594)
Sets the type of filtering used to separate the data dependent
noise from the random noise and the periodic noise.
:MEASure:NOISe:LOCation
(see page 595)
Specifies the noise measurement location within the bit where
0% is the beginning of the bit, 50% is the middle of the bit, and
100% is the end of the bit.
:MEASure:NOISe:RN (see
page 598)
Specifies a known amount of random noise.
:MEASure:NOISe:SCOPe:RN
(see page 599)
Specifies the removal of the oscilloscope's calibrated random
noise from the reported RN.
:MEASure:NOISe:STATe (see
page 600)
Enables or disables the NOISe measurements.
:MEASure:NOISe:UNITs (see
page 601)
Sets the unit of measure for NOISe measurements to volts or
unit amplitude.
:MEASure:RJDJ:RJ (see
page 642)
Specifies a known amount of random jitter.
