36 Agilent Infiniium 9000 Series Oscilloscopes Programmer's Reference
1 What's New
What's New in Version 4.10
New command descriptions for Version 4.10 of the Infiniium 9000 Series
oscilloscope software appear below.
New Commands
Changed
Commands
Command Description
:MEASure:NOISe:METHod
(see page 596)
Lets you select the method for random noise (RN) analysis,
either the SPECtral method or BOTH the spectral and tail fit
methods.
:MEASure:NOISe:REPort (see
page 597)
When BOTH is selected for :MEASure:NOISe:METHod, you can
select SPECtral or TAILfit to specify which method is used for
the reports.
:MEASure:RJDJ:METHod (see
page 638)
Lets you select the method for random jitter (RJ) analysis, either
the SPECtral method or BOTH the spectral and tail fit methods.
:MEASure:RJDJ:REPort (see
page 641)
When BOTH is selected for :MEASure:RJDJ:METHod, you can
select SPECtral or TAILfit to specify which method is used for
the reports.
:MEASure:TIEFilter:SHAPe
(see page 709)
Specifies the shape of the TIE filter edge(s).
Command Description
:MEASure:NOISe:ALL (see
page 592)
New results can be returned depending on the
:MEASure:NOISe:METHod and :MEASure:NOISe:REPort
settings.
:MEASure:RJDJ:ALL (see
page 629)
New results can be returned depending on the
:MEASure:RJDJ:METHod and :MEASure:RJDJ:REPort settings.
