What's New 1
Agilent Infiniium 9000 Series Oscilloscopes Programmer's Reference 35
What's New in Version 4.20
New command descriptions for Version 4.20 of the Infiniium 9000 Series
oscilloscope software appear below.
New Commands
Changed
Commands
Obsolete
Commands
Command Description
:DISPlay:CGRade:SCHeme
(see page 299)
Lets you set the color grade scheme to CLASsic or TEMP.
:FUNCtion<F>:FFT:TDELay
(see page 337)
Sets the time delay for the FFT phase function.
:MEASure:CHARge (see
page 504)
When N2820A/N2821A high-sensitivity current probes are
connected, this command/query measures the total current
consumption over time with the results listed in ampere-hours
(Ah).
:MEASure:CLOCk:METHod:JT
F (see page 513)
Specifies the clock recovery PLL's response in terms of the
Jitter Transfer Function's (JTF) 3 dB bandwidth.
:MEASure:CLOCk:METHod:OJ
TF (see page 515)
Specifies the clock recovery PLL's response in terms of the
Observed Jitter Transfer Function's (OJTF) 3 dB bandwidth.
Command Description
:MEASure:CLOCk:METHod
(see page 507)
The command options for specifying clock recovery PLL options
have been moved to the new commands
:MEASure:CLOCk:METHod:JTF and
:MEASure:CLOCk:METHod:OJTF.
Obsolete Command Current Command
Equivalent
Description
:MEASure:DDPWS :MEASure:RJDJ:ALL?
(see page 629)
The :MEASure:RJDJ:ALL? query returns all of
the RJDJ jitter measurements.
