158 Agilent Infiniium 9000 Series Oscilloscopes Programmer's Reference
9 Acquire Commands
:ACQuire:POINts[:ANALog]
(Memory depth)
Command
:ACQuire:POINts[:ANALog] {AUTO | <points_value>}
The :ACQuire:POINts[:ANALog] command sets the requested analog
memory depth for an acquisition. Before you download data from the
oscilloscope to your computer, always query the points value with the
:WAVeform:POINts? query or :WAVeform:PREamble? query to determine the
actual number of acquired points.
You can set the points value to AUTO, which allows the oscilloscope to
select the optimum memory depth and display update rate.
<points_value> An integer representing the memory depth.
The range of points available for a channel depends on the oscilloscope
settings of sampling mode, sampling rate, and trigger sweep. The following
tables show the range of memory values for the different memory options.
Table 6 500M Memory Option Installed
Sampling mode and sample rate Trigger Sweep
Single Auto or Triggered
Normal, Peak Detect, and High
Resolution Modes: 4 channel mode
16 to 512.5 Mpts 16 to 256.25 Mpts
Normal, Peak Detect, and High
Resolution Modes: 2 channel mode
16 to1025 Mpts 16 to 612.5 Mpts
Normal and High Resolution with
Averaging
16 to 2,050,00
Equivalent Time Mode 16 to 262,144 kpts
Table 7 200M Memory Option Installed
Sampling mode and sample rate Trigger Sweep
Single Auto or Triggered
Normal, Peak Detect, and High
Resolution Modes: 4 channel mode
16 to 205 Mpts
Normal, Peak Detect, and High
Resolution Modes: 2 channel mode
16 to 410 Mpts
Normal and High Resolution with
Averaging
16 to 2,050,00
Equivalent Time Mode 16 to 262,144 kpts
