1156 Agilent Infiniium 9000 Series Oscilloscopes Programmer's Reference
36 Obsolete and Discontinued Commands
:MEASure:CLOCk:METHod
(deprecated)
Command
:MEASure:CLOCk:METHod {FOPLL,<data_rate>,<loop_bandwidth>}
| {EQFOPLL,<data_rate>,<loop_bandwidth>}
| {SOPLL,<data_rate>,<loop_bandwidth>, <damping_factor>}
| {EQSOPLL,<data_rate>,<loop_bandwidth>, <damping_factor>}
| {PCIE,{DEEMphasis | TRANsition | BOTH}}
| {FC,{FC1063 | FC2125 | FC425}}
| {EXPFOPLL,<source>,{RISing | FALLing | BOTH},
<multiplier>,<clock_freq>,<loop_bandwidth>}
| {EXPSOPLL,<source>,{RISing | FALLing | BOTH},
<multiplier>,<clock_freq>,<loop_bandwidth>,<damping_fact>}
| {EXPlicit,<source>,{RISing | FALLing | BOTH}[,<multiplier>]}
| {FIXed,{AUTO | {SEMI[,<data_rate>]} | <data_rate>}}
| {FLEXR,<baud_rate>}
| {FLEXT,<baud_rate>}
The :MEASure:CLOCk:METHod command sets the clock recovery method
to:
• FOPLL (first order phase- locked loop).
• SOPLL (second order phase-locked loop).
• EQFOPLL (equalized first order phase- locked loop).
• EQSOPLL (equalized second order phase-locked loop).
• PCIE (PCI Express).
• FC (Fibre Channel).
• EXPFOPLL (Explicit First Order PLL).
• EXPSOPLL (Explicit Second Order PLL).
• EXPlicit (Explicit Clock).
• FIXed (Constant Frequency).
• FLEXR (FlexRay Receiver).
• FLEXT (FlexRay Transmitter).
NOTE
Some of these command options have been deprecated — options for specifying clock
recovery PLL options have been moved to the new commands
":MEASure:CLOCk:METHod:JTF" on page 513 and ":MEASure:CLOCk:METHod:OJTF" on
page 515. See also ":MEASure:CLOCk:METHod" on page 507.
NOTE
:MEASure:CLOCk commands are available when clock recovery is used by licensed
software (like the E2688A High Speed Serial software or the N5400A/N5401A EZJIT Plus
jitter analysis software).
