Waveform Commands 34
Agilent Infiniium 9000 Series Oscilloscopes Programmer's Reference 1121
See Also • ":WAVeform:DATA?" on page 1091
Acquisition Mode The acquisition sampling mode of the waveform. (See ":ACQuire:MODE"
on page 156.)
Complete The complete value is the percent of time buckets that are complete. The
complete value is ignored when it is sent to the oscilloscope in the
preamble. (See the ":WAVeform:COMPlete?" on page 1088 query.)
X Units The X-axis units of the waveform. (See the ":WAVeform:XUNits?" on
page 1137 query.)
Y Units The Y-axis units of the waveform. (See the ":WAVeform:YUNits?" on
page 1143 query.)
Band Pass The band pass consists of two values that are estimates of the
maximum and minimum bandwidth limits of the source waveform. The
bandwidth limit is computed as a function of the selected coupling and
filter mode. (See the ":WAVeform:BANDpass?" on page 1086 query.)
Table 24 Waveform Preamble Elements (continued)
Element Description
