33 Trigger Commands
:TRIGger:ADVanced:STATe:LOGic
Command :TRIGger:ADVanced:STATe:LOGic {{CHANnel<N> | <channel_list>
| DIGital<M>},{LOW|HIGH|DONTcare|RISing| FALLing}}
This command defines the logic state of the specified source for the state
pattern. The command produces a settings conflict on a channel that has
been defined as the clock.
<N> An integer, 1- 2, for two channel Infiniium Oscilloscope. An integer, 1- 4, for
all other Infiniium Oscilloscope models.
<channel_list> The channel range is from 0 to 15 in the following format.
<M> An integer, 0-15. The digital channels are only available on the MSO
oscilloscopes or DSO models with the MSO license installed.
Query
:TRIGger:ADVanced:STATe:LOGic? {CHANnel<N> | <channel_list> | DIGital<M
>}
The query returns the logic state definition for the specified source.
<N> N is the channel number, an integer in the range of 1 - 4.
Returned Format
[:TRIGger:ADVanced:STATe:LOGic {CHANnel<N>|<channel_list>|DIGital<M>},]
{LOW|HIGH|DONTcare|RISing|FALLing}<NL>
(@1,5,7,9) channels 1, 5, 7, and 9 are turned on.
(@1:15) channels 1 through 15 are turned on.
(@1:5,8,14) channels 1 through 5, channel 8, and channel 14 are turned on.
