33 Trigger Commands
:TRIGger:ADVanced:PATTern:LOGic
Command :TRIGger:ADVanced:PATTern:LOGic {{CHANnel<N> | <channel_list> | DIGital<
M>},{HIGH|LOW|DONTcare|RISing|FALLing}}
This command defines the logic criteria for a selected channel.
<N> An integer, 1-4.
<M> An integer, 0-15. The digital channels are only available on the MSO
oscilloscopes or DSO models with the MSO license installed.
<channel_list> The channel range is from 0 to 15 in the following format.
Query
:TRIGger:ADVanced:PATTern:LOGic? {CHANnel<N> | <channel_list> | DIGital<
M>}
The query returns the current logic criteria for a selected channel.
Returned Format
[:TRIGger:ADVanced:PATTern:LOGic {CHANnel<N>|<channel_list> | DIGital<M>
},] {HIGH|LOW|DONTcare|RISing|FALLing}<NL>
(@1,5,7,9) channels 1, 5, 7, and 9 are turned on.
(@1:15) channels 1 through 15 are turned on.
(@1:5,8,14) channels 1 through 5, channel 8, and channel
14 are turned on.
