98 Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:SAVE:MASK[:STARt]
[<file_spec>] (see
page 425)
n/a <file_spec> ::= {<internal_loc>
| <file_name>}
<internal_loc> ::= 0-3; an
integer in NR1 format
<file_name> ::= quoted ASCII
string
:SAVE:PWD <path_name>
(see page 426)
:SAVE:PWD? (see
page 426)
<path_name> ::= quoted ASCII
string
:SAVE:SETup[:STARt]
[<file_spec>] (see
page 427)
n/a <file_spec> ::= {<internal_loc>
| <file_name>}
<internal_loc> ::= 0-9; an
integer in NR1 format
<file_name> ::= quoted ASCII
string
:SAVE:WAVeform[:STARt
] [<file_name>] (see
page 428)
n/a <file_name> ::= quoted ASCII
string
:SAVE:WAVeform:FORMat
<format> (see
page 429)
:SAVE:WAVeform:FORMat
? (see page 429)
<format> ::= {ALB | ASCiixy | CSV
| BINary | NONE}
:SAVE:WAVeform:LENGth
<length> (see
page 430)
:SAVE:WAVeform:LENGth
? (see page 430)
<length> ::= 100 to max. length;
an integer in NR1 format
:SAVE:WAVeform:SEGMen
ted <option> (see
page 431)
:SAVE:WAVeform:SEGMen
ted? (see page 431)
<option> ::= {ALL | CURRent}
Table 19 :SAVE Commands Summary (continued)
Command Query Options and Query Returns
Table 20 :SBUS Commands Summary
Command Query Options and Query Returns
n/a :SBUS:CAN:COUNt:ERRor
? (see page 434)
<frame_count> ::= integer in NR1
format
n/a :SBUS:CAN:COUNt:OVERl
oad? (see page 435)
<frame_count> ::= integer in NR1
format
:SBUS:CAN:COUNt:RESet
(see page 436)
n/a n/a
n/a :SBUS:CAN:COUNt:TOTal
? (see page 437)
<frame_count> ::= integer in NR1
format
