Technical data

96 Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:MTESt:SOURce
<source> (see
page 402)
:MTESt:SOURce? (see
page 402)
<source> ::= {CHANnel<n> | NONE}
<n> ::= {1 | 2 | 3 | 4} for 4ch
models
<n> ::= {1 | 2} for 2ch models
n/a :MTESt:TITLe? (see
page 403)
<title> ::= a string of up to 128
ASCII characters
Table 16 :MTESt Commands Summary (continued)
Command Query Options and Query Returns
Table 17 :POD<n> Commands Summary
Command Query Options and Query Returns
:POD<n>:DISPlay {{0 |
OFF} | {1 | ON}} (see
page 405)
:POD<n>:DISPlay? (see
page 405)
{0 | 1}
<n> ::= 1-2 in NR1 format
:POD<n>:SIZE <value>
(see page 406)
:POD<n>:SIZE? (see
page 406)
<value> ::= {SMALl | MEDium |
LARGe}
:POD<n>:THReshold
<type>[suffix] (see
page 407)
:POD<n>:THReshold?
(see page 407)
<n> ::= 1-2 in NR1 format
<type> ::= {CMOS | ECL | TTL |
<user defined value>}
<user defined value> ::= value in
NR3 format
[suffix] ::= {V | mV | uV }
Table 18 :RECall Commands Summary
Command Query Options and Query Returns
:RECall:FILename
<base_name> (see
page 410)
:RECall:FILename?
(see page 410)
<base_name> ::= quoted ASCII
string
:RECall:IMAGe[:STARt]
[<file_spec>] (see
page 411)
n/a <file_spec> ::= {<internal_loc>
| <file_name>}
<internal_loc> ::= 0-9; an
integer in NR1 format
<file_name> ::= quoted ASCII
string
:RECall:MASK[:STARt]
[<file_spec>] (see
page 412)
n/a <file_spec> ::= {<internal_loc>
| <file_name>}
<internal_loc> ::= 0-3; an
integer in NR1 format
<file_name> ::= quoted ASCII
string
