Commands Quick Reference 4
Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide 89
:MEASure:FALLtime
[<source>] (see
page 334)
:MEASure:FALLtime?
[<source>] (see
page 334)
<source> ::= {CHANnel<n> |
FUNCtion | MATH} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15 | FUNCtion
| MATH} for MSO models
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= time in
seconds between the lower and
upper thresholds in NR3 format
:MEASure:FREQuency
[<source>] (see
page 335)
:MEASure:FREQuency?
[<source>] (see
page 335)
<source> ::= {CHANnel<n> |
FUNCtion | MATH} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15 | FUNCtion
| MATH} for MSO models
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= frequency in
Hertz in NR3 format
:MEASure:NWIDth
[<source>] (see
page 336)
:MEASure:NWIDth?
[<source>] (see
page 336)
<source> ::= {CHANnel<n> |
FUNCtion | MATH} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15 | FUNCtion
| MATH} for MSO models
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= negative
pulse width in seconds-NR3 format
:MEASure:OVERshoot
[<source>] (see
page 337)
:MEASure:OVERshoot?
[<source>] (see
page 337)
<source> ::= {CHANnel<n> |
FUNCtion | MATH}
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= the percent of
the overshoot of the selected
waveform in NR3 format
:MEASure:PERiod
[<source>] (see
page 339)
:MEASure:PERiod?
[<source>] (see
page 339)
<source> ::= {CHANnel<n> |
FUNCtion | MATH} for DSO models
<source> ::= {CHANnel<n> |
DIGital0,..,DIGital15 | FUNCtion
| MATH} for MSO models
<n> ::= 1-2 or 1-4 in NR1 format
<return_value> ::= waveform
period in seconds in NR3 format
Table 15 :MEASure Commands Summary (continued)
Command Query Options and Query Returns
