Technical data

Commands Quick Reference 4
Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide 85
:FUNCtion:REFerence
<level> (see
page 287)
:FUNCtion:REFerence?
(see page 287)
<level> ::= the value at center
screen in NR3 format.
The range of legal values is
+/-10 times the current
sensitivity of the selected
function.
:FUNCtion:SCALe
<scale
value>[<suffix>] (see
page 288)
:FUNCtion:SCALe? (see
page 288)
<scale value> ::= integer in NR1
format
<suffix> ::= {V | dB}
:FUNCtion:SOURce1
<source> (see
page 289)
:FUNCtion:SOURce1?
(see page 289)
<source> ::= {CHANnel<n> | GOFT}
<n> ::= {1 | 2 | 3 | 4} for 4ch
models
<n> ::= {1 | 2} for 2ch models
GOFT is only for FFT, INTegrate,
DIFFerentiate, and SQRT
operations.
:FUNCtion:SOURce2
<source> (see
page 290)
:FUNCtion:SOURce2?
(see page 290)
<source> ::= {CHANnel<n> | NONE}
<n> ::= {{1 | 2} | {3 | 4}} for
4ch models, depending on SOURce1
selection
<n> ::= {1 | 2} for 2ch models
:FUNCtion:SPAN <span>
(see page 291)
:FUNCtion:SPAN? (see
page 291)
<span> ::= the current frequency
span in NR3 format.
Legal values are 1 Hz to 100 GHz.
:FUNCtion:WINDow
<window> (see
page 292)
:FUNCtion:WINDow?
(see page 292)
<window> ::= {RECTangular |
HANNing | FLATtop | BHARris}
Table 11 :FUNCtion Commands Summary (continued)
Command Query Options and Query Returns
Table 12 :HARDcopy Commands Summary
Command Query Options and Query Returns
:HARDcopy:AREA <area>
(see page 295)
:HARDcopy:AREA? (see
page 295)
<area> ::= SCReen
:HARDcopy:APRinter
<active_printer> (see
page 296)
:HARDcopy:APRinter?
(see page 296)
<active_printer> ::= {<index> |
<name>}
<index> ::= integer index of
printer in list
<name> ::= name of printer in
list
