Commands Quick Reference 4
Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide 83
:DISPlay:PERSistence
<value> (see
page 263)
:DISPlay:PERSistence?
(see page 263)
<value> ::= {MINimum | INFinite}}
:DISPlay:SOURce
<value> (see
page 264)
:DISPlay:SOURce? (see
page 264)
<value> ::= {PMEMory{0 | 1 | 2 |
3 | 4 | 5 | 6 | 7 | 8 | 9}}
:DISPlay:VECTors {{1
| ON} | {0 | OFF}}
(see page 265)
:DISPlay:VECTors?
(see page 265)
{1 | 0}
Table 9 :DISPlay Commands Summary (continued)
Command Query Options and Query Returns
Table 10 :EXTernal Trigger Commands Summary
Command Query Options and Query Returns
:EXTernal:BWLimit
<bwlimit> (see
page 268)
:EXTernal:BWLimit?
(see page 268)
<bwlimit> ::= {0 | OFF}
:EXTernal:IMPedance
<value> (see
page 269)
:EXTernal:IMPedance?
(see page 269)
<impedance> ::= {ONEMeg | FIFTy}
:EXTernal:PROBe
<attenuation> (see
page 270)
:EXTernal:PROBe? (see
page 270)
<attenuation> ::= probe
attenuation ratio in NR3 format
n/a :EXTernal:PROBe:ID?
(see page 271)
<probe id> ::= unquoted ASCII
string up to 11 characters
:EXTernal:PROBe:STYPe
<signal type> (see
page 272)
:EXTernal:PROBe:STYPe
? (see page 272)
<signal type> ::= {DIFFerential |
SINGle}
:EXTernal:PROTection[
:CLEar] (see
page 273)
:EXTernal:PROTection?
(see page 273)
{NORM | TRIP}
:EXTernal:RANGe
<range>[<suffix>]
(see page 274)
:EXTernal:RANGe? (see
page 274)
<range> ::= vertical full-scale
range value in NR3 format
<suffix> ::= {V | mV}
:EXTernal:UNITs
<units> (see
page 275)
:EXTernal:UNITs? (see
page 275)
<units> ::= {VOLT | AMPere}
