82 Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
:DIGital<n>:POSition
<position> (see
page 253)
:DIGital<n>:POSition?
(see page 253)
<n> ::= 0-15; an integer in NR1
format
<position> ::= 0-7 if display
size = large, 0-15 if size =
medium, 0-31 if size = small
:DIGital<n>:SIZE
<value> (see
page 254)
:DIGital<n>:SIZE?
(see page 254)
<value> ::= {SMALl | MEDium |
LARGe}
:DIGital<n>:THReshold
<value>[suffix] (see
page 255)
:DIGital<n>:THReshold
? (see page 255)
<n> ::= 0-15; an integer in NR1
format
<value> ::= {CMOS | ECL | TTL |
<user defined value>}
<user defined value> ::= value in
NR3 format from -8.00 to +8.00
[suffix] ::= {V | mV | uV}
Table 8 :DIGital<n> Commands Summary (continued)
Command Query Options and Query Returns
Table 9 :DISPlay Commands Summary
Command Query Options and Query Returns
:DISPlay:CLEar (see
page 258)
n/a n/a
:DISPlay:DATA
[<format>][,][<area>]
[,][<palette>]<displa
y data> (see
page 259)
:DISPlay:DATA?
[<format>][,][<area>]
[,][<palette>] (see
page 259)
<format> ::= {TIFF} (command)
<area> ::= {GRATicule} (command)
<palette> ::= {MONochrome}
(command)
<format> ::= {TIFF | BMP |
BMP8bit | PNG} (query)
<area> ::= {GRATicule | SCReen}
(query)
<palette> ::= {MONochrome |
GRAYscale | COLor} (query)
<display data> ::= data in IEEE
488.2 # format
:DISPlay:LABel {{0 |
OFF} | {1 | ON}} (see
page 261)
:DISPlay:LABel? (see
page 261)
{0 | 1}
:DISPlay:LABList
<binary block> (see
page 262)
:DISPlay:LABList?
(see page 262)
<binary block> ::= an ordered
list of up to 75 labels, each 10
characters maximum, separated by
newline characters
