Commands Quick Reference 4
Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide 81
n/a :CHANnel<n>:PROBe:ID?
(see page 241)
<probe id> ::= unquoted ASCII
string up to 11 characters
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:PROBe:SKE
W <skew_value> (see
page 242)
:CHANnel<n>:PROBe:SKE
W? (see page 242)
<skew_value> ::= -100 ns to +100
ns in NR3 format
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:PROBe:STY
Pe <signal type> (see
page 243)
:CHANnel<n>:PROBe:STY
Pe? (see page 243)
<signal type> ::= {DIFFerential |
SINGle}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:PROTectio
n (see page 244)
:CHANnel<n>:PROTectio
n? (see page 244)
{NORM | TRIP}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:RANGe
<range>[suffix] (see
page 245)
:CHANnel<n>:RANGe?
(see page 245)
<range> ::= Vertical full-scale
range value in NR3 format
[suffix] ::= {V | mV}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:SCALe
<scale>[suffix] (see
page 246)
:CHANnel<n>:SCALe?
(see page 246)
<scale> ::= Vertical units per
division value in NR3 format
[suffix] ::= {V | mV}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:UNITs
<units> (see
page 247)
:CHANnel<n>:UNITs?
(see page 247)
<units> ::= {VOLT | AMPere}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:VERNier
{{0 | OFF} | {1 |
ON}} (see page 248)
:CHANnel<n>:VERNier?
(see page 248)
{0 | 1}
<n> ::= 1-2 or 1-4 in NR1 format
Table 7 :CHANnel<n> Commands Summary (continued)
Command Query Options and Query Returns
Table 8 :DIGital<n> Commands Summary
Command Query Options and Query Returns
:DIGital<n>:DISPlay
{{0 | OFF} | {1 |
ON}} (see page 251)
:DIGital<n>:DISPlay?
(see page 251)
{0 | 1}
<n> ::= 0-15; an integer in NR1
format
:DIGital<n>:LABel
<string> (see
page 252)
:DIGital<n>:LABel?
(see page 252)
<string> ::= any series of 10 or
less ASCII characters enclosed in
quotation marks
<n> ::= 0-15; an integer in NR1
format
