80 Agilent InfiniiVision 6000 Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
n/a :CALibrate:TEMPeratur
e? (see page 227)
<return value> ::= degrees C
delta since last cal in NR3
format
n/a :CALibrate:TIME? (see
page 228)
<return value> ::=
<hours>,<minutes>,<seconds>; all
in NR1 format
Table 6 :CALibrate Commands Summary (continued)
Command Query Options and Query Returns
Table 7 :CHANnel<n> Commands Summary
Command Query Options and Query Returns
:CHANnel<n>:BWLimit
{{0 | OFF} | {1 |
ON}} (see page 232)
:CHANnel<n>:BWLimit?
(see page 232)
{0 | 1}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:COUPling
<coupling> (see
page 233)
:CHANnel<n>:COUPling?
(see page 233)
<coupling> ::= {AC | DC}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:DISPlay
{{0 | OFF} | {1 |
ON}} (see page 234)
:CHANnel<n>:DISPlay?
(see page 234)
{0 | 1}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:IMPedance
<impedance> (see
page 235)
:CHANnel<n>:IMPedance
? (see page 235)
<impedance> ::= {ONEMeg | FIFTy}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:INVert
{{0 | OFF} | {1 |
ON}} (see page 236)
:CHANnel<n>:INVert?
(see page 236)
{0 | 1}
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:LABel
<string> (see
page 237)
:CHANnel<n>:LABel?
(see page 237)
<string> ::= any series of 10 or
less ASCII characters enclosed in
quotation marks
<n> ::= 1-2 or 1-4 in NR1 format
:CHANnel<n>:OFFSet
<offset>[suffix] (see
page 238)
:CHANnel<n>:OFFSet?
(see page 238)
<offset> ::= Vertical offset
value in NR3 format
[suffix] ::= {V | mV}
<n> ::= 1-2 or 1-4; in NR1 format
:CHANnel<n>:PROBe
<attenuation> (see
page 239)
:CHANnel<n>:PROBe?
(see page 239)
<attenuation> ::= Probe
attenuation ratio in NR3 format
<n> ::= 1-2 or 1-4r in NR1 format
:CHANnel<n>:PROBe:HEA
D[:TYPE] <head_param>
(see page 240)
:CHANnel<n>:PROBe:HEA
D[:TYPE]? (see
page 240)
<head_param> ::= {SEND0 | SEND6 |
SEND12 | SEND20 | DIFF0 | DIFF6 |
DIFF12 | DIFF20 | NONE}
<n> ::= 1-2 or 1-4 in NR1 format
